Place of Origin: | Hebei,china |
Brand Name: | XKh |
Certification: | iso,ce |
Model Number: | Razor barbed wire |
Minimum Order Quantity: | 1 piece |
---|---|
Price: | Price based on quantity |
Packaging Details: | waterproof paper inside , woven bag out side ,pallet or cartn also available |
Delivery Time: | 7 days |
Payment Terms: | L/C,TT |
Supply Ability: | 4 cotainers /week |
Material: | Hot Dipped Galvanized Iron /steel Wire With Steel Sheet | Core Wire Thickness: | 2mm-2.5mm |
---|---|---|---|
Blade Thickness: | 0.35mm-0.5mm | Type: | BTO-10,BTO-22,BTO-28,BTO-30,CBT-60,CBT-60 |
Coil Diameter: | 300mm,350mm,400mm,450mm,500mm,550mm,600mm,700mm,900mm,1050mm | Weight: | 3 Kg - 15 Kg /coil |
Surface Treatment: | Glavanized , PVC Coating ,Epoxy | Machine: | HIgh Speed Punching Machine |
Main Market: | Afirca, Middle East , Europe , Americ | Fuction: | For Protecting . Gurding , For War ,road ,, |
BTO-22 - Material. HD Galvanized Zinc as below photo
Thickness: 0.50 mm +/- 0.05 mm
Wire diam: 2.50 mm +/- 0.05 mm
Bars length: 22 mm +/- 1 mm
Bars spacing: 34 mm +/- 1mm
450 mm diameter and 35 rings
Straight length: 46.5 mt per roll after pull open
Standard covered length: 10 mt
Inner packing: in plastic film
Outer packing: in weaving brag strip.
1. Introduction of 450mm 600mm 700mm 900mm 1000mm outside diameter concertina stainless steel razor wire
Stainless steel 304 316 core wire and stainless steel sheet in 304 or 316
( also can be electric galvanized or hot dipped galvanized & pvc coating )
Core wire diameter: usually 2.5mm, can be customized
Razor thickness: 0.3-0.6mm
Barb length: 11-67mm
Barb width: 14-23mm
Barb spacing: 25--102mm
Common Types: BTO-10, BTO-20, BTO-22, BTO-28, CBT-65 etc.
Razor Barbed Tape Wire Specification |
||||
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
450mm |
33 |
7-8M |
CBT-60.65 |
Single coil |
500mm |
56 |
12-13M |
CBT-60.65 |
Single coil |
700mm |
56 |
13-14M |
CBT-60.65 |
Single coil |
960mm |
56 |
14-15M |
CBT-60.65 |
Single coil |
450mm |
56 |
8-9M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
500mm |
56 |
9-10M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
600mm |
56 |
10-11M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
600mm |
56 |
8-10M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
700mm |
56 |
10-12M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
800mm |
56 |
11-13M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
900mm |
56 |
12-14M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
960mm |
56 |
13-15M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
980mm |
56 |
14-16M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
Packing of razor barbed wire :
Application of Cheap China Sharp blade BTO-22/CBT-65 Razor Wire
razor type barbed wire is widely used in high-grade residence district, warehouses, prisons and in military fields and other sites requiring severe fencing and security.
