Security Protection Galvanized Fence Welded Razor Barbed Wire Mesh
Descriptions :
Welded razor wire mesh is a multi-functional, high security mesh fencing made of straight-blade netting welded together, packaging into a roll form for transport. Welded Razor Wire Mesh is used in operations to pave the field after the installation of a blade barrier. This product can protect you and your property, and ensures the safety of the protective barriers.
This welded razor wire mesh security fence product is almost impossible to climb or cut off with the standard tools, also it has a neat appearance.
Welded razor wire mesh is installed in various parts of the world's airports, military bases, water substation, the border fence, oil depots, factories and so on.
Hole shape :
| Item |
Blade Style |
Thickness (mm) |
Wire Dia. (mm) |
Barb Length (mm) |
Barb Width (mm) |
Barb spacing (mm) |
| BTO-12 |
 |
0.5±0.05 |
2.5±0.1 |
12±1 |
15±1 |
26±1 |
| BTO-18 |
|
0.5±0.05 |
2.5±0.1 |
18±1 |
15±1 |
33±1 |
| BTO-22 |
|
0.5±0.05 |
2.5±0.1 |
22±1 |
15±1 |
34±1 |
| BTO-28 |
|
0.5±0.05 |
2.5±0.1 |
28±1 |
15±1 |
45±1 |
| BTO-30 |
|
0.5±0.05 |
2.5±0.1 |
30±1 |
18±1 |
45±1 |
| CBT-60 |
|
0.6±0.05 |
2.5±0.1 |
60±2 |
32±1 |
100±2 |
| CBT-65 |
|
0.6±0.05 |
2.5±0.1 |
65±2 |
21±1 |
100±2 |
Hole Type:
1.Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
2.Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.
| Gauge diameter |
Hole shape |
Mesh width |
Suited blade specifications |
| 100mm×100mm |
Square hole,diamond |
1.2m ~ 2.4m |
BTO-10.12.18.22.28.30, CBT-60.65 |
| 100mm×150mm |
Square hole,diamond |
1.2m ~ 2.4m |
BTO-10.12.18.22.28.30, CBT-60.65 |
| 100mm×200mm |
Square hole,diamond |
1.2m ~ 2.4m |
BTO-10.12.18.22.28.30, CBT-60.65 |
| 150mm×300mm |
Square hole,diamond |
1.2m ~ 2.4m |
BTO-10.12.18.22.28.30, CBT-60.65 |
| other nets hole can according to customers' special needs) |
Benefits :
- A. It is almost impossible to climb.
- B. High-strength steel core very difficult to cut off.
- C. Powerful security fence barriers neat appearance.
- D. No secondary use, so he will not be stolen.
- E. Extremely simple to install, needs three to four to install molding.
Features :
1 .Non-climbing;
2. Robust welded structure;
3 .Zinc coating improve corrosive resistance;
4. Available in square and diamond profile.
Applications :
- Prison
- Industrial Facilities (Storage ,Factory, Bases and warehouses)
- Roadside (Villas ,parks gardens,school )
- Water-saving and environmental protection enterprises
- Nuclear power stations, and power plants, gas supply and distribution facilities
- National defense facilities, ministry of interior and prisons
- Mining areas and border areas
Key Parameters :
- 1.Surface treatment
- 2.Hole Size
- 2.Blade type :
- 3.Width :
- 4.Length :
- 5. Quantity :
