Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life

Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life

    • Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life
    • Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life
    • Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life
    • Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life
  • Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life

    Product Details:

    Place of Origin: Hebei,china
    Brand Name: XKh
    Certification: iso,ce
    Model Number: Razor barbed wire

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: Negotiable
    Delivery Time: 7 days
    Payment Terms: T/T, L/C
    Supply Ability: 50tons/day
    Contact Now
    Detailed Product Description
    Item: Ripper Razor Flat Wrap Wire In Panel Used On Fence , Wall Or Dayliy Life . Material:: Hot Dipped /electric Galvanized Iron Wire Or Stainless Steel Wire As Core Wire ,hot Dipped Galvanized Sheet Or Stainless Steel Sheet As Blade
    Blade Type:: Bto 10 , 15,18, 22 , 28,30 And CBT 60 65 Coil Diameter: 300mm,450mm,600mm,900mm Etc
    Coil Clipped Space:: 10-30cm Shape:: Flat Wrap Panel Sheet
    Core Wire Diameter:: 1.8mm-2.75mm (2.5mm) Blade Thickness:: 0.3-0.5mm (0.45mm)
    Application:: As Standalone Fence, Or Can Be Amalgamated With Existing Chain Link Mesh Or Other Fence , Tied On That High Light:: 450mm Razor Barbed Wire, Fence Razor Barbed Wire, 300mm Fence Razor Wire

    Ripper razor flat wrap wire in panel used on fence , wall or dayliy life .

    Descriptions :

    • Razor wire flat wrap coils are made of high tensile razor wire, clapped into a flat panel formation
    • ripper razor flat wrap is a mesh of metal strips with sharp edges whose purpose is to prevent passage by humans. The term "razor wire", through long usage, has generally been used to describe barbed tape products. While razor wire is much sharper than the standard barbed wire, it is not actually razor sharp.the multiple blades of a razor wire fence are designed to inflict serious cuts on anyone attempting to climb through and therefore have a strong psychological deterrent effect. In many high-security applications, barbed tape supplanted barbed wire, which could be circumvented relatively quickly by humans with tools, while penetrating razor wire barriers without tools is very slow and difficult, giving security forces more time to respond.

    Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life 0

    History :

    Barbed tape was first manufactured by Germany during World War I, as an expedient measure during a shortage of wire. Since it was simply punched out of a rolled ribbon of steel tape, it could be manufactured much more quickly. This early barbed tape had triangular barbs and no reinforcing wire; consequently, it was more difficult to cut with ordinary wire cutters, easier to cut with shears, and was generally of lower tensile strength.from the early 1970s, unreinforced barbed tape was commonly used in perimeter barriers of US prisons. In the early 1980s, several manufacturers began offering barbed tape with an embedded reinforcing wire and the product has been the subject to a patent dispute. Early brand names of reinforced barbed tape included "Man Barrier" and "Razor Ribbon". The latter probably lent its name to the modern slang term.

    Quick details :

    • Types of Razor wires: BTO-10, BTO-12, BTO-18, BTO-22, BTO-28, BTO-30, CBT-65, CBT-60
    • Material of Razor Wire:
      • Normal hot dipped galvanized razor wire (40–60 g/m2)
      • Heavily zinc coated razor wire (70–270 g/m2)
      • Stainless steel 304 or 316 grades razor wire
    • Clips of concertina wire: fixed by clips between coils to coils into panel
    • Coil Diameter of concertina wire: 300/450/500/600/700/800/950/1000 mm
    • Coil clipped space : 10-35cm (as per request , 15-20cm will be in big density and high security )
    • Core wire thickness :1.8-2.75mm(2.5mm is the standard )
    • Blade thickness : 0.3-0.5mm (0.45mm is the standard )
    • structure shape : in roll (15m is the standard )or in sheet (2m is better considering container size )
    • Package of razor wires
      • Waterproof paper inside, woven bag outside, then 50 rolls/bundle or as required
      • Nude package, then packing by wooden pallet or in bulk
    Razor Wire Flat wrap Specifications - Standard Coil Sizes
    Height Length Weight
    500 mm
    (20 inch)
    15 m
    (50 ft.)
    9.5 kg
    (21 lbs)
    700 mm
    (28 inch)
    15 m
    (50 ft.)
    13 kg
    (29 lbs)
    900 mm
    (36 inch)
    15 m
    (50 ft.)
    14.5 kg
    (32 lbs)


    Item Blade Style Thickness (mm) Wire Dia. (mm) Barb Length (mm) Barb Width (mm) Barb spacing (mm)
    BTO-12 BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
    BTO-18 BTO-18 0.5±0.05 2.5±0.1 18±1 15±1 33±1
    BTO-22 BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
    BTO-28 BTO-28 0.5±0.05 2.5±0.1 28±1 15±1 45±1
    BTO-30 BTO-30 0.5±0.05 2.5±0.1 30±1 18±1 45±1
    CBT-60 BTO-60 0.6±0.05 2.5±0.1 60±2 32±1 100±2
    CBT-65 BTO-65 0.6±0.05 2.5±0.1 65±2 21±1 100±2


    Maintenance of Flat Razor Wire Toppings:

    Minimal maintenance is required once installed; razor wire usually stays effective for as long as needed. However, for optimum security, a regular check of the perimeter for any trapped debris, litter or bags within the wires is required to ensure the wire maintains its effectiveness. Any damaged wires can be quickly and easily repaired without removing the entire structure.


    It is recommended that when handling razor wire, gauntlet gloves are worn to protect the installer from the sharp edges of the wire.

    Flat Razor Wire Toppings Legislation:

    Warning signs must be installed along the fence line, warning the general public of the dangerous razor wire above.

    Applications :

    The wire and strip are galvanized to prevent corrosion.currently, barbed tape has been widely used by many countries in military field, prisons, detention houses, government buildings and other national security facilities. Recently years, barbed tape has apparently become the most popular high-class fencing wire for not only military and national security applications, but also for cottage and society fence, and other private buildings.


    Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life 8

    Notice :

    1. Flat wrap razor wire normally the coil diameter is 450mm ,500mm, 900mm
    2. Roll length : standard is 15m or 16m , for the sheet is 2mtrs
    3. Clipped space , we will suggest you when you have special request .
    4. Packing : roll compacted - normally 5 rolls as one bundle .1 layer packing is thick waterproof paper , 2 layers -add woven bag . 3 layers need to add pallet .
    5. Payment term : L/C,T/T or any 3rd platform's insurance order way .

    Ripper Razor Flat Wrap Wire In Panel For Fence Wall Dayliy Life 9
