Hot Dipped Galvanized BTO-22 2.5MM 900mm 13 kg /roll Concertina Razor Barbed Wire
1. Introduction of Hot Dipped Galvanized BTO-22 2.5MM 900mm 13 kg Concertina Razor Barbed Wire
Razor wire is also named concertina coils or razor type barbed wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With beautiful and sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
2. Specification of Hot Dipped Galvanized BTO-22 2.5MM 900mm 13 kg Concertina Razor Barbed Wire
Material:
hot dipped (electro) galvanized wire and stainless steel wire as core wire
hot dipped (electro) galvanized sheet and stainless steel sheet as blade
Surface Treatment : galvanized or PVC coated
Core wire diameter: usually 2.5mm, can be customized
Razor thickness: 0.3-0.6mm
Barb length: 11-67mm
Barb width: 14-23mm
Barb spacing: 25--102mm
Common Types: BTO-10, BTO-20, BTO-22, BTO-28, CBT-65 etc.
|
Razor Barbed Tape Wire Specification
|
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Type
|
Notes
|
|
450mm
|
33
|
7-8M
|
CBT-60.65
|
Single coil
|
|
500mm
|
56
|
12-13M
|
CBT-60.65
|
Single coil
|
|
700mm
|
56
|
13-14M
|
CBT-60.65
|
Single coil
|
|
960mm
|
56
|
14-15M
|
CBT-60.65
|
Single coil
|
|
450mm
|
56
|
8-9M (3 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
|
500mm
|
56
|
9-10M (3 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
|
600mm
|
56
|
10-11M (3 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
|
600mm
|
56
|
8-10M (5 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
|
700mm
|
56
|
10-12M (5 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
|
800mm
|
56
|
11-13M (5 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
|
900mm
|
56
|
12-14M (5 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
|
960mm
|
56
|
13-15M (5 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
|
980mm
|
56
|
14-16M (5 CLIPS)
|
BTO-10.12.18.22.28.30
|
Cross type
|
