Razor Welded Wire Mesh = Razor Wire by welded .
Welded razor wire mesh is also known as straight-line razor wire, is by the blade thorn rope straight welded together, is modified according to the welded wire mesh, main function is to guard against theft, climbing and isolation.
Welded Razor Wire Mesh Hole Type
- Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
- Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.
Welded Razor Wire Mesh Blade Type:
| Model |
Thickness |
Wire Dia |
Length |
Width |
spacing |
| BTO-10 |
0.5mm |
2.5mm |
12mm |
13mm |
26mm |
| BTO-12 |
0.5mm |
2.5mm |
12mm |
15mm |
26mm |
| BTO-18 |
0.5mm |
2.5mm |
18mm |
15mm |
33mm |
| BTO-22 |
0.5mm |
2.5mm |
22mm |
15mm |
34mm |
| BTO-28 |
0.5mm |
2.5mm |
28mm |
15mm |
34mm |
| BTO-30 |
0.5mm |
2.5mm |
30mm |
18mm |
34mm |
| CBT-60 |
0.6mm |
2.5mm |
60mm |
32mm |
96mm |
| CBT-65 |
0.6mm |
2.5mm |
65mm |
21mm |
100mm |
Welded Razor Wire Mesh Surface Treatment
- Galvanized Coating:50-60g/m2 , 80-100g/m2 , 200-250g/m2
- Pvc Coated Color: green,red,white etc.
Welded Razor Wire Mesh - Square hole type - Galvanized surface treatment :
Welded Razor Wire Mesh - Diamond hole type - PVC coating surface treatment :
Razor welded wire mesh 's Packing :
Hard carton in both ending , woven bag , nude , pallet
Except in roll , also can be cut into fixed sheet size - fixed width x fixed width .
Application :
safety - security in fence using
