450mm/600mm/900mm/1050mm Hot Dipped Galvanized Concertina Razor Barbed Wire for Protecting

450mm/600mm/900mm/1050mm Hot Dipped Galvanized Concertina Razor Barbed Wire for Protecting

450mm/600mm/900mm/1050mm Hot Dipped Galvanized Concertina Razor Barbed Wire for Protecting

Product Details:

Place of Origin: Hebei,china
Brand Name: XKh
Certification: iso,ce
Model Number: Razor barbed wire

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: Price based on quantity
Packaging Details: waterproof paper inside , woven bag out side ,pallet or cartn also available
Delivery Time: 7 days
Payment Terms: L/C,TT
Supply Ability: 4 cotainers /week
Contact Now
Detailed Product Description
Material: Hot Dipped Galvanized Iron /steel Wire With Steel Sheet Core Wire Thickness: 2mm-2.5mm
Blade Thickness: 0.35mm-0.5mm Type: BTO-10,BTO-22,BTO-28,BTO-30,CBT-60,CBT-60
Coil Diameter: 300mm,350mm,400mm,450mm,500mm,550mm,600mm,700mm,900mm,1050mm Weight: 3 Kg - 15 Kg /coil
Surface Treatment: Glavanized , PVC Coating ,Epoxy Machine: HIgh Speed Punching Machine

Sharp galvanized razor barbed wire Razor barbed wire fencing is usually made of galvanized steel blade or stainless steel blade. Twopieces of stainless steel razor wire or zinc-coated razor wire can be bounded together by clips to make it stronger. The spiral intersecting
Barbed wire presents an intersecting shape after opening with beautiful outlook and practical property
1. Material:
A. Core wire material: Galvanized wire and stainless steel wire.
B. Blade material: Galvanized sheet and stainless steel sheet.
2. Specification:
1)Razor thickness: 0.5mm, 0.6mm
2)Wire diameter: 2.2mm, 2.5mm, 3.0mm
3)Razor width: 15 mm
4)Razor length: 22 mm
5)barb spacing: 26mm
6)Outside diameter of roll: Can be: 450mm, 500mm, 600mm,
730mm, 900mm, 1meter,
Or as customers' specific request.
7)Number of loops: 33--102
8)Standard spreading length per roll: 8m --16m
9)Razor barbed type: Cross type
10)Packing: Compression rolls, water-proof paper inside, woven bag outside or in carton
11)Surface treatment: Galvanized or PVC coated
3. Features: Razor barbed wire is also named Tape Wire, Razor Tape Wire, Barbed Tape or Barbed Tape Wire. It can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult. The wire an d strip are galvanized to prevent corrosion.
4. Application:
Razor barbed wire is widely used by in military field, prisons, detention houses, government buildings and other national security facilities; It is also used as fence for cottage and society fence, and other private buildings
Outside Diameter No. of Loops Standard Length per Coil Type Notes
450mm 112 17M BTO-10. concertina
500mm 102 16M BTO-10. concertina
600mm 86 14M BTO-10. concertina
700mm 72 12M BTO-10. concertina
800mm 64 10M BTO-10. concertina
960mm 52 9M BTO-10. concertina
Length, diameter can be made according to customers request.
Core wire material: galvanized wire and stainless steel wire.
Blade material: galvanized sheet and stainless steel sheet.
