Name: High Tensile Hot Dipped Galvanized Sharp Razor Barbed Wire for Security Fence
Brand: Xing Kuan Highui Wire Mesh Products Co.,ltd
SKU: Razor barbed wire
Availability: InStock

Home Products Razor Barbed Wire

High Tensile Hot Dipped Galvanized Sharp Razor Barbed Wire for Security Fence

Product Details:

Place of Origin:	Hebei,china
Brand Name:	XKh
Certification:	iso,ce
Model Number:	Razor barbed wire

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	Price based on quantity
Packaging Details:	waterproof paper inside , woven bag out side ,pallet or cartn also available
Delivery Time:	7 days
Payment Terms:	L/C,TT
Supply Ability:	4 cotainers /week

Contact Now

Detailed Product Description

Razor Barbed wire

Material: High quality low carbon steel wire

Usage: Mainly used for the importance safeguard, such as the frontier defense line wire, sentry, prison, military base and airport, etc.

Specification: BTO-10, 12, 18, 22, 28, 30, CBT-60, 65.

1. Razor thickness: 0.5mm
2. Wire diameter: 2.5mm
3. Razor width: 15 mm
4. Razor length: 22 mm
5. Outside diameter of roll: 600 mm
6. Number of loops: 33--102
7. Standard spreading length per roll: 8m --16m
8. Razor barbed type: Cross type

Razor Blade Type and Specification

Reference Number	Thickness	Wire Diameter	Barb Length	Barb Width	Barb Spacing
BTO-10	0.5 ± 0.05	2.5 ± 0.1	10 ± 1	13 ± 1	26 ± 1
BTO-12	0.5 ± 0.05	2.5 ± 0.1	12 ± 1	15 ± 1	26 ± 1
BTO-18	0.5 ± 0.05	2.5 ± 0.1	18 ± 1	15 ± 1	33 ± 1
BTO-22	0.5 ± 0.05	2.5 ± 0.1	22 ± 1	15 ± 1	34 ± 1
BTO-28	0.5 ± 0.05	2.5 ± 0.1	28 ± 1	15 ± 1	45 ± 1
BTO-30	0.5 ± 0.05	2.5 ± 0.1	30 ± 1	18 ± 1	45 ± 1

Outer diameter	No. of loops	Standard length per coil	Type	Notes
450mm	33	7m-8m	CBT-65	Single coil
500mm	41	10m	CBT-65	Single coil
700mm	41	10m	CBT-65	Single coil
960mm	54	11m-15m	CBT-65	Single coil
500mm	102	15m-18m	BTO-12,18,22,28,30	Cross type
600mm	86	13m-16m	BTO-12,18,22,28,30	Cross type
700mm	72	12m-15m	BTO-12,18,22,28,30	Cross type
800mm	64	13m-15m	BTO-12,18,22,28,30	Cross type
960mm	52	12m-15m	BTO-12,18,22,28,30	Cross type
