15m Length Flat Razor Wire Fencing Barbed for Type Ribbon Panels

15m length 450,00,900mmof Flat Razor Wire Barbed for Type Ribbon Panels

Descriptions :

• Flat razor barbed wire is a new type of razor barbed wire. We presse the single loop razor barbed wire into flat, or press two loops into flat then expand them across. We usually use it together with beenline razor barbed wire to build a defencing wall, or use it alone as a fence.
• The thickness steel plate used by the flat razor wire is 0.5mm. Although the thin steel plate does not affect the protective effect of the blade wire mesh, it will reduce the service life in the long run.We provide razor barbed wire core wire uses high tension galvanized steel wire (the amount of zinc is not less than 40g/square). It has a long life and is not easy to be damaged; the overall structure of the buckle is firm and not easy to be damaged.
• Razor wire flat wrap coils are made of high tensile razor wire, clapped into a flat panel formation

Quick details :

• Types of Razor wires: BTO-10, BTO-12, BTO-18, BTO-22, BTO-28, BTO-30, CBT-65, CBT-60
• Material of Razor Wire:
  • Normal hot dipped galvanized razor wire (40–60 g/m2)
  • Heavily zinc coated razor wire (70–270 g/m2)
  • Stainless steel 304 or 316 grades razor wire
• Clips of concertina wire: fixed by clips between coils to coils into panel
• Coil Diameter of concertina wire: 300/450/500/600/700/800/950/1000 mm
• Coil clipped space : 10-35cm (as per request , 15-20cm will be in big density and high security )
• Core wire thickness :1.8-2.75mm(2.5mm is the standard )
• Blade thickness : 0.3-0.5mm (0.45mm is the standard )
• structure shape : in roll (15m is the standard )or in sheet (2m is better considering container size )
• Package of razor wires
  • Waterproof paper inside, woven bag outside, then 50 rolls/bundle or as required
  • Nude package, then packing by wooden pallet or in bulk

Item	Blade Style	Thickness (mm)	Wire Dia. (mm)	Barb Length (mm)	Barb Width (mm)	Barb spacing (mm)
BTO-12		0.5±0.05	2.5±0.1	12±1	15±1	26±1
BTO-18		0.5±0.05	2.5±0.1	18±1	15±1	33±1
BTO-22		0.5±0.05	2.5±0.1	22±1	15±1	34±1
BTO-28		0.5±0.05	2.5±0.1	28±1	15±1	45±1
BTO-30		0.5±0.05	2.5±0.1	30±1	18±1	45±1
CBT-60		0.6±0.05	2.5±0.1	60±2	32±1	100±2
CBT-65		0.6±0.05	2.5±0.1	65±2	21±1	100±2

Maintenance of Flat Razor Wire Toppings:

Minimal maintenance is required once installed; razor wire usually stays effective for as long as needed. However, for optimum security, a regular check of the perimeter for any trapped debris, litter or bags within the wires is required to ensure the wire maintains its effectiveness. Any damaged wires can be quickly and easily repaired without removing the entire structure.

Safety:

It is recommended that when handling razor wire, gauntlet gloves are worn to protect the installer from the sharp edges of the wire.

Flat Razor Wire Toppings Legislation:

Warning signs must be installed along the fence line, warning the general public of the dangerous razor wire above.

Notice :

1. Flat wrap razor wire normally the coil diameter is 450mm ,500mm, 900mm
2. Roll length : standard is 15m or 16m , for the sheet is 2mtrs
3. Clipped space , we will suggest you when you have special request .
4. Packing : roll compacted - normally 5 rolls as one bundle .1 layer packing is thick waterproof paper , 2 layers -add woven bag . 3 layers need to add pallet .
5. Payment term : L/C,T/T or any 3rd platform's insurance order way .
