Flat Razor Wire Razor Wire Flat Wrap Flat Wrap Razor Wire Coil BTO-10

High security Flat Razor Wire / Razor Wire Flat Wrap /Flat wrap razor wire coil

Descriptions :

Flat razor wire is ideal for use in more crowded conditions than standard concertina razor wire. Flat Razor Wire coils are located in one plain panel, making the design much more compact.This razor wire security fence topping is designed to protect facilities in urban areas where you can not use spiral razor security barrier because of its size. Flat razor mesh barrier security can be designed and installed onto our range of perimeter fences and gates.

Quick details :

• Material :Hot dipped /electric galvanized iron wire or stainless steel wire as core wire ,hot dipped galvanized sheet or stainless steel sheet as blade
• Blade type : BTO 10 ,22,25,28,30 & CBT 60 or 65(The blade normally we choose BTO-10,BTO-22 500mm coil diameter is very popular for top installation .)
• Coil diameter : 300mm,450mm,500mm,600mm,700mm,730mm,850mm,900mm,1050mm,1200mm (300-1200mm)
• Coil clipped space : 10-35cm (as per request , 15-20cm will be in big density and high security )
• Core wire thickness :1.8-2.75mm(2.5mm is the standard )
• Blade thickness : 0.3-0.5mm (0.45mm is the standard )
• structure shape : in roll (15m is the standard )or in sheet (2m is better considering container size )

Space control : -considering the security perfomance , we have to do suitable space .

-IT IS AVILABLE TO ADJUST space . ( example : both are 900mm coil diameter , but the density and space is different ) we use more razor wire for density type , but the security is more higher .

Flat Razor Wire Features:

• A neat, unobtrusive appearance
• Simple and easy installation
• Reduces boundary overhang and public liability
• Easily fixed over gate pivots
• Compliments our existing range of perimeter security fencing solutions
• Difficult to cut with standard cutting tools
• Easily installed above or against existing mesh fencing systems
• An effective but neat barrier solution

Applications :

This razor wire security fence topping is designed to protect facilities in urban areas where you can not use spiral razor security barrier because of its size. Flat Wrap Razor Wire Mainly used in Fencing.Widely used in military, field, prison, detention houses, government buildings and other national security facilities. Also fencing of residences, villa wall and windows, express way, railway, national border lines, etc.

Notice :

1. Flat wrap razor wire normally the coil diameter is 450mm ,500mm, 900mm
2. Roll length : standard is 15m or 16m , for the sheet is 2mtrs
3. Clipped space , we will suggest you when you have special request .
4. Packing : roll compacted - normally 5 rolls as one bundle .1 layer packing is thick waterproof paper , 2 layers -add woven bag . 3 layers need to add pallet .
5. Payment term : L/C,T/T or any 3rd platform's insurance order way .
