Flat Wrap Razor Barbed Wire 500mmx15m Fitted To Welded Mesh Fence

Razor Wire Flat Wrap 500mm x 15m fitted to welded mesh fence as a barrier

Descriptions :

500 mm high razor wire flatwrap fitted to our welded mesh fence provides a neat but effective barrier fencing. Installion of razor wire flatwrap is particularly simple when it is fitted by overlapping the fence mesh. 900mm razor wire flatwrap installed to a brick wall provides a high barrier.

Quality Control :

The quality of raw materials for manufacturing razor wire flatwrap: Galvanized barbed tape thickness should lie between 0.5-0.55mm. Using of a thin coil does not initially affected the efficiency of the concertina wire, but in the long run will reduce the service life of the barricades several times. The wire must be galvanized or stainless steel, and if the wire is black iron without zinc coating, soon you will lose the barricade. The finished concertina wire coil must be tight. The galvanizing surface of the razor wire flatwrap after compressing should be damaged during the process.

Quick details :

• Material :Hot dipped /electric galvanized iron wire or stainless steel wire as core wire ,hot dipped galvanized sheet or stainless steel sheet as blade
• Blade type : BTO 10 ,22,25,28,30 & CBT 60 or 65(The blade normally we choose BTO-10,BTO-22 500mm coil diameter is very popular for top installation .)
• Coil diameter : 300mm,450mm,500mm,600mm,700mm,730mm,850mm,900mm,1050mm,1200mm (300-1200mm)
• Coil clipped space : 10-35cm (as per request , 15-20cm will be in big density and high security )
• Core wire thickness :1.8-2.75mm(2.5mm is the standard )
• Blade thickness : 0.3-0.5mm (0.45mm is the standard )
• structure shape : in roll (15m is the standard )or in sheet (2m is better considering container size )

Applications :

Flat wrap coil installation is particularly simple when it is fitted by overlapping the fence mesh. In addition, the flatwrap coil can be used in the following forms:

Notice :

1. Flat wrap razor wire normally the coil diameter is 450mm ,500mm, 900mm
2. Roll length : standard is 15m or 16m , for the sheet is 2mtrs
3. Clipped space , we will suggest you when you have special request .
4. Packing : roll compacted - normally 5 rolls as one bundle .1 layer packing is thick waterproof paper , 2 layers -add woven bag . 3 layers need to add pallet .
5. Payment term : L/C,T/T or any 3rd platform's insurance order way .
