20cm space Flat Wrap Razor Wire 900mm Coil Diameter for fence

Product Details:

Place of Origin:	Hebei Province,china
Brand Name:	Xingkuan
Certification:	iso9000
Model Number:	Razor barbed wire

Payment & Shipping Terms:

Minimum Order Quantity:	1 roll
Price:	Negotiable
Delivery Time:	7 days
Payment Terms:	T/T, L/C
Supply Ability:	50tons/day

Contact Now

Detailed Product Description

Item:	900mm Coil Diameter 20-30cm Space Flat Wrap Razor Wire In Panel Used On Fence	Material::	Hot Dipped /electric Galvanized Iron Wire Or Stainless Steel Wire As Core Wire ,hot Dipped Galvanized Sheet Or Stainless Steel Sheet As Blade
Blade Type::	Bto 10 , 15,18, 22 , 28,30 And CBT 60 65	Coil Diameter:	300mm,450mm,600mm,900mm Etc
Coil Clipped Space::	10-30cm	Shape::	Flat Wrap Panel Sheet
Core Wire Diameter::	1.8mm-2.75mm (2.5mm)	Blade Thickness::	0.3-0.5mm (0.45mm)
Application::	As Standalone Fence, Or Can Be Amalgamated With Existing Chain Link Mesh Or Other Fence , Tied On That	High Light::	30cm Flat Wrap Razor Wire, Flat Wrap Razor Wire 900mm, Fence Coil Razor Wire

900mm coil diameter 20-30cm space flat wrap razor wire in panel used on fence

Descriptions :

The flat spiral barrage 900 mm with a density of stacking turns 4.2 turns at 1 meter. The coils are
connected in 13 points stapling staples. Staples are made of galvanized steel. The flat spiral fence has high resistance to
destruction. Even with the full cross-section cutting it does not change the geometry of obstacles, if the armature of the fence
is still intact. Flat barrier concertina has a nice appearance, easy to mount the brackets and rebar wire

20cm space Flat Wrap Razor Wire 900mm Coil Diameter for fence 0

Quick details :

Material :Hot dipped /electric galvanized iron wire or stainless steel wire as core wire ,hot dipped galvanized sheet or stainless steel sheet as blade
Blade type : BTO 10 ,15,18,22,25,28,30 & CBT 60 or 65
Coil clipped space : 10-35cm (as per request , 15-20cm will be in big density and high security )
Core wire thickness :1.8-2.75mm(2.5mm is the standard )
Blade thickness : 0.3-0.5mm (0.45mm is the standard )
structure shape : in roll (15m is the standard )or in sheet (2m is better considering container size )

20cm space Flat Wrap Razor Wire 900mm Coil Diameter for fence 1

Height	Length	Weight
500 mm (20 inch)	15 m (50 ft.)	9.5 kg (21 lbs)
700 mm (28 inch)	15 m (50 ft.)	13 kg (29 lbs)
900 mm (36 inch)	15 m (50 ft.)	14.5 kg (32 lbs)

Specification	Blade thickness	Wire diameter	Blade length	Blade width	Blade spacing
BTO-10	0.5±0.05	2.5±0.1	10±1	13±1	26±1
BTO-12	0.5±0.05	2.5±0.1	12±1	15±1	26±1
BTO-18	0.5±0.05	2.5±0.1	18±1	15±1	33±1
BTO-22	0.5±0.05	2.5±0.1	22±1	15±1	34±1
BTO-28	0.5±0.05	2.5±0.1	28	15	45±1
BTO-30	0.5±0.05	2.5±0.1	30	18	45±1
CBT-60	0.6±0.05	2.5±0.1	60±2	32±1	100±2
CBT-65	0.6±0.05	2.5±0.1	65±2	21±1	100±2

Applications :

Flat wrap coils can be used in the following forms:

Installed against the existing smooth wire mesh fence;
Fitted to the welded mesh fence;
Fitted by overlapping the fence mesh;
Installed to the brick wall directly.

20cm space Flat Wrap Razor Wire 900mm Coil Diameter for fence 2

Notice :

Flat wrap razor wire normally the coil diameter is 450mm ,500mm, 900mm
Roll length : standard is 15m or 16m , for the sheet is 2mtrs
Clipped space , we will suggest you when you have special request .
Packing : roll compacted - normally 5 rolls as one bundle .1 layer packing is thick waterproof paper , 2 layers -add woven bag . 3 layers need to add pallet .
Payment term : L/C,T/T or any 3rd platform's insurance order way .

20cm space Flat Wrap Razor Wire 900mm Coil Diameter for fence 3

20cm space Flat Wrap Razor Wire 900mm Coil Diameter for fence 5
