Hexagonal wire mesh is also known by the name of chicken mesh
Wire materials: hexagonal wire mesh is manufactured in galvanized iron or PVC coated wire
Application:
Hexagonal wire mesh with its good corrosion resistance and oxidation resistance, serves well as strengthening, protection and temperature keeping materials in the form of mesh container, stone cage, isolation wall, boiler cover or poultry fence in construction, chemical, breeding, garden and food processing industries
Galvanized hex. wire netting in normal twist (width of 0.5 to 2.0m)
Mesh: 10 to 100mm
Wire gauge: 14 to 27BWG
Galvanized hex. wire netting in reverse twist (width of 0.5 to 2.0m)
Mesh: 25 to 75mm
Wire gauge: 18 to 22BWG
Hex. wire netting PVC-coated (width of 0.5 to 2.0m)
Mesh: 13 to 50mm
Wire diameter: 0.1 to 1.4mm
| Hexagonal wire mesh fence |
| mesh |
Min. Gal.v.
G/SQ.M |
Width |
Wire Gauge (Diameter)
BWG |
| Inch |
mm |
Tolerance(mm) |
| 3/8" |
10mm |
±1.0 |
0.7mm - 145 |
2' - 1M |
27, 26, 25, 24, 23 |
| 1/2" |
13mm |
±1.5 |
0.7mm - 95 |
2' - 2M |
25, 24, 23, 22, 21 |
| 5/8" |
16mm |
±2.0 |
0.7mm - 70 |
2' - 2M |
27, 26, 25, 24, 23, 22 |
| 3/4" |
20mm |
±3.0 |
0.7mm - 55 |
2' - 2M |
25, 24, 23, 22, 21, 20, 19 |
| 1" |
25mm |
±3.0 |
0.9mm - 55 |
1' - 2M |
25, 24, 23, 22, 21, 20, 19, 18 |
| 1-1/4" |
31mm |
±4.0 |
0.9mm - 40 |
1' - 2M |
23, 22, 21, 20, 19, 18 |
| 1-1/2" |
40mm |
±5.0 |
1.0mm - 45 |
1' - 2M |
23, 22, 21, 20, 19, 18 |
| 2" |
50mm |
±6.0 |
1.2mm - 40 |
1' - 2M |
23, 22, 21, 20, 19, 18 |
| 2-1/2" |
65mm |
±7.0 |
1.0mm - 30 |
1' - 2M |
21, 20, 19, 18 |
| 3" |
75mm |
±8.0 |
1.4mm - 30 |
2' - 2M |
20, 19, 18, 17 |
| 4" |
100mm |
±8.0 |
1.6mm - 30 |
2' - 2M |
19, 18, 17, 16 |
Technical Note:
1,Standard roll length: 20m,25m,27m,30m,50m
2,Special sizes available at request
|
Packing & Loading :
A>Waterproof paper only + Label /no label
B>Shrink film only + label /no label
C>waterprrof paper inside + shirnk film outside + label
D> A/B/C+ Good Pallet
Application:
Galvanized hexagonal wire mesh
- Rabbit fencing
- Chicken runs & Poultry fences
- Garden fences
- Deer fencing / Deer Control (1.8m high version available)
- Tree Guards
We are one of professional manufacturer and exporter for wire and wire mesh for 30 years . Our products has been export to UK ,poland ,Spain , Dubai , canada , Austrialia , Singapore , Philipines , Indonesia , Kenya amd other zone .
Wish to receive your detailed inquiry within 24 hours we will give you our professional and best reply .
