Galvanized Weave Chicken Wire Mesh 16 Gauge Continuous Twist

Product Details:

Place of Origin:	Hebei,china
Brand Name:	XKh
Certification:	iso,ce
Model Number:	chicken wire netting

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	Negotiate
Packaging Details:	waterproof paper , shrinkfilm , pallet or as per request
Delivery Time:	5-8 working days
Payment Terms:	L/C, T/T
Supply Ability:	1000m2/day

Contact Now

Detailed Product Description

Item:	16 Gauge Continuous Twist Heavy Galvanized Weave Chicken Wire Mesh	Material:	Low Carbon Iron Wire (electric Galvanied Or Hot Dipped Galvanized Or Pvc Coated Wire ) , Stainless Steel Wire , Copper Wire Or Copper Painted Wire ,etc
Wire Diameter:	Galvanized Wire From 0.3-2.0mm, PVC Coated Wire 0.8-2.6mm	Aperture:	10-100mm (eg .3/8"-10mm,1/2"-13mm, ,3/4"-20mm,1"-25mm,1/2"-40mm,,2" -50mm, Etc )
Width:	0.5m-2.5m(eg. 3ft -0.914m , 4 Ft -1.22m , 5 Ft -1.55mm Etc )	Length:	5-60m (eg . 10m , 20m ,30m ,50m Etc )
Weaving:	Normal/straight Twist , Reverse Twist	Surface Treatment:	Electric Galvanized Before Weaving, Hot-dipped Galvanized Before Weaving,hot-dipped Galvanized After Weaving, PVC Coated.
High Light:	Chicken Wire Mesh 16 Gauge , Chicken Wire Mesh Galvanized , Continuous Twist Wire Mesh 16 Gauge

16 Gauge Continuous Twist Heavy Galvanized Weave chicken wire mesh
Descriptions :

This extra heavy hexagonal netting, known as Paddle Tennis wire or Platform Tennis wire, is manufactured to meet the rugged specification requirements of paddle tennis courts.
The rolls weigh 328 pounds. Two 180' rolls will do a single court. In addition to netting for paddle tennis courts, it also makes an ideal overhead electrical grid in bumper car rides.
Heavily galvanized after weave (GAW), this continuous twist mesh will last for years. After weaving the 16 gauge 1" mesh hexagonal netting fence is dipped in a rust inhibiting bath of molten zinc.

Quick details :

16 GAUGE wire diameter
25mm hole size
72" width
for paddle court

Galvanized hexagonal wire mesh STANDARD Specifications

Galvanized hex. wire netting in normal twist (width of 0.5M-2.0M)
Mesh		Wire Gauge (BWG)
Inch	mm	Wire Gauge (BWG)
3/8"	10mm	27,26,25,24,23,22,21
1/2"	13mm	25,24,23,22,21,20,
5/8"	16mm	27,26,25,24,23,22
3/4"	20mm	25,24,23,22,21,20,19
1"	25mm	25,24,23,22,21,20,19,18
1-1/4"	32mm	22,21,20,19,18
1-1/2"	40mm	22,21,20,19,18,17
2"	50mm	22,21,20,19,18,17,16,15,14
3"	75mm	21,20,19,18,17,16,15,14
4"	100mm	17,16,15,14

Galvanized hexagonal wire mesh in reverse twist (width of 0.5M-2.0M)
Mesh		Wire Gauge(BWG)	Reinforcement
Inch	mm	(BWG)	Width(ft)	Strand
1"	25mm	22,21,20,18	2'	1
1-1/4"	32mm	22,21,20,18	3'	2
1-1/2"	40mm	20,19,18	4'	3
2"	50mm	20,19,18	5'	4
3"	75mm	20,19,18	6'	5

hexagonal wire mesh PVC-coated (width of 0.5M-2.0M)
Mesh		Wire Dia(mm)
Inch	mm	Wire Dia(mm)
1/2"	13mm	0.9mm,0.1mm
1"	25mm	1.0mm,1.2mm,1.4mm
1-1/2"	40mm	1.0mm,1.2mm,1.4mm,1.6mm
2"	50mm	1.0mm,1.2mm,1.4mm,1.6mm

Other size can be customerized according to client's real need !
Applications :
Rabbit fencing
Chicken runs & Poultry fences
Garden fences
Deer fencing / Deer Control (1.8m high version available)
Tree Guards

Notice :

Packing : Waterproof-paper (balck ,brown , white color ,etc ) , shrink film or add pallet + label , or as per cusomter request
Payment terms : TT,L/C ,or 3rd platform through insurance order
Be sure to take into account the wire diameter, aperture and roll size when selecting mesh for a project.
Small size of smaple is free .
