stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration

stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration

    • stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration
    • stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration
    • stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration
    • stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration
    • stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration
  • stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration

    Product Details:

    Place of Origin: Hebei,china
    Brand Name: XKh
    Certification: iso,ce
    Model Number: continuous filter belt for scren changer in plastic extruder machine

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: Price based on quantity
    Packaging Details: film+waterproof paper , carton or wooden case is available
    Delivery Time: ready sock in 3 days
    Payment Terms: L/C,TT
    Supply Ability: 10000rolls /month
    Contact Now
    Detailed Product Description
    Material: 302,304,304A,316 Width: 97,127,130,140,150mm , Etc
    Mesh Counting: 152x24,260x40,132x17,72x15 , 100 Mesh , 120 Mesh ,200 Mesh , Etc Length: 10 M /roll , 20m/roll , Customerized
    Function: Used On The Automatic Screen Changer, For Filtering

    stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration

     NO.1:Mesh belt : 132x17 mesh, 152x24 mesh, 260x40 mesh, 72x15mesh.150x17 mesh.

    132x17mesh: 0.3x0.45mm,4.4kg/sqm.

    152x24mesh: 0.3x0.4mm. 3.5kg/sqm.

    260x40mesh: 0.15x0.27mm.2.1kg/sqm.

    72x15mesh: 0.45x0.55mm. 5kg/sqm.

    Width: 97mm, 100mm, 110mm, 120mm, 127mm, 130mm, 133mm, 150mm.

    Length: 10m , 20m / roll.



    Material: Stainless steel 304.

    Woven style: RDW woven. Reversed dutch woven .

    Used on the automatic screen changer, for filtering.

    NO.2:WE produce reversed dutch woven filter cloth ( RDW FILTER CLOTH ) for 1x30m / roll.

    RDW Filter cloth:

    130x30mesh, 0.2x0.4mm. 1x30m. 80kg/ roll.  SS316L.

    175x45mesh, 0.15x0.3mm, 1x30m.  58kg / roll. SS316L.

    290x70mesh, 0.09x0.2mm, 1x30m. 39kg / roll. SS316L.



    Custom designs are also available



    Basic specifications



    Mesh

    Wire Dai.(mm)

    Thickness(mm)

    Width(cm)

    45x15

    0.45x0.6

     1.75

    9.7-28

    48X10

    0.50X0.50

    3.6kg/sq.m

    9.7-28

    72x15

    0.45x0.55

    1.7

    9.7-28

    90X17

    0.23X0.55

    2.48kg/sq.m

    9.7-28

    110X17

    0.23X0.55

    2.6kg/sq.m

    9.7-28

    110X21

    0.23X0.35

    2.0kg/sq.m

    9.7-28

    120x16

    0.35x0.45

     1.36

    9.7-28

    132x17

    0. 3x0.45

    1.3

    9.7-28

    152x24

    0.3x0.40

    1.2

    9.7-28

    160x18

    0.28x0.45

     1.27

    8-85

    200x40

    0.15x0.27

    0.7

    8-130

    260x40

    0.15 x0.27

     0.65

    8-130

    300x40

    0.15 x0.27

     0.65

    8-130

    360x40

    0.13 x0.27

    0.6

    8-130

     Special specification we can produce according to customers' requirements.



    A : Do you have stock or not ?



    Yes , we have a lot of stock(  800rolls stock always )  ,fast delivery .



    B:  Do you accept small order -1 roll ?



    Yes, surely , 1 roll is no problem for us .



    C : Do you offer free sample for our testing ?



    Yes , we surely offer free sample for your quality confirmation .



    Automatic Screen changer screen belt Features:

    With smooth surface, high hardness, working continuously, no deformation, high temperature resistance, corrosion resistance, flexible working with excellent filtering performance.



    stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration



    Continuous automatic filter belt

    Mesh/inch

    Wire Dia.(mm)

    Width(mm)

    Length/Roll(m)

    72/15

    0.45/0.55

    97---400

    10/20

    120/15

    0.35/0.45

    97---400

    10/20

    132/17

    0.32/0.45

    97---400

    10/20

    150/17

    0.3/0.45

    97---400

    10/20

    152/24

    0.27/0.4

    97---400

    10/20

    170/17

    0.27/0.45

    97---400

    10/20

    180/18

    0.27/0.45

    97---400

    10/20

    200/40

    0.17/0.27

    97---400

    10/20

    260/40

    0.15/0.25

    97---400

    10/20



    Other sizes are avaliable according to clients'request.



    Edge of Automatic Screen changer screen belt:



    stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration



    Applications of Automatic Screen changer screen belt :







    stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration

    High Tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry for PP, PE, ABS, PS, PMMA and other materials.



    Packing of Automatic Screen changer screen belt  :



    Waterproof paper on each roll + carton / wooden case



    stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filterationstainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration

    stainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filterationstainless steel 302 ,304 Belt for Continuous Belt Screen Changer for Polymer Filteration

    Shipping  of Automatic Screen changer screen belt :

     By sea or By Air - Express , No problem for us .

     Do you accept Paypal , west Union ?

      Yes It is ok for us ,No problem .
