Place of Origin: | china factory |
Brand Name: | xk highui |
Certification: | ISO9001:2000,CE,SGS,COC |
Model Number: | continuous filter belt for scren changer in plastic extruder machine |
Minimum Order Quantity: | 1 piece |
---|---|
Price: | Price based on quantity |
Packaging Details: | film+waterproof paper , carton or wooden case is available |
Delivery Time: | ready sock in 3 days |
Payment Terms: | L/C,TT |
Supply Ability: | 10000rolls /month |
Material: | Stainless Steel 302,304,304A,316 | Mesh: | 152x24,260x40,132x17, 100 ,200 , 160 ,180 ,120 Mesh |
---|---|---|---|
Weave Type: | Plain , Twill | Function: | Used In Screen Changer |
Fair We Attend: | China West Plastics And Rubber Fair | The Fair We Atten: | China Wire Mesh Exhibition |
MOQ: | 1 Roll |
152/24 Continuous automatic filter belt
Application
Using the dense warp , thin weft knitting method, used in plastics extruder solution filtration, chemical mechanical filtration, such as solid-liquid separation filter, so that in cleaning backwash filter oil, residues process has good mechanical stability and filtering accuracy.
Features
With smooth surface, high hardness, network continuously, not deformation, high temperature resistance, corrosion resistance, network advantages such as flexible, has excellent filtering performance, good filtering precision, load high strength, high temperature resistant, good low temperature resistance, etc
Continuous automatic filter belt | |||
Mesh/inch |
Wire Dia.(mm) |
Width(mm) |
Length/Roll(m) |
72/15 |
0.45/0.55 |
97---400 |
10/20 |
120/15 |
0.35/0.45 |
97---400 |
10/20 |
132/17 |
0.32/0.45 |
97---400 |
10/20 |
150/17 |
0.3/0.45 |
97---400 |
10/20 |
152/24 |
0.27/0.4 |
97---400 |
10/20 |
170/17 |
0.27/0.45 |
97---400 |
10/20 |
180/18 |
0.27/0.45 |
97---400 |
10/20 |
200/40 |
0.17/0.27 |
97---400 |
10/20 |
260/40 |
0.15/0.25 |
97---400 |
10/20 |
