Place of Origin: | China |
Brand Name: | xk highui |
Certification: | ISO9001:2000,CE,SGS,COC |
Model Number: | continuous filter belt for scren changer in plastic extruder machine |
Minimum Order Quantity: | 1 piece |
---|---|
Price: | Price based on quantity |
Packaging Details: | film+waterproof paper , carton or wooden case is available |
Delivery Time: | ready sock in 3 days |
Payment Terms: | L/C,TT |
Supply Ability: | 10000rolls /month |
--100% Stainless Steel With 304 & 316 Grade
--Extensive Products Range
--Widest Range Of Size (4 Mesh To 1500 Mesh)
--Ready-to-use (5mm To 800mm Diameter)
--Ready Availability
--World-Class Quality With Smooth Cutting Burr Free Edge
--Comprehensive Raw Material Inventory
--Specialized Cutting Dies And Tool For High Precision
--High Pressure And High Temperature Withstanding Capabilities.
Preferred Stainless Steel Filter Screen Belt Supplier
1.Material:SS302#,SS304#,SS316L# etc.
2.Mesh:72/15,132/17,152/24,152/30,260/40,etc.
3.Length of Wire Mesh Filter Belt:10mtrs or 20mtrs
Width of Wire Mesh Filter Belt:50mm-300mm
Stainless Steel Automatic Belt Type Filter Screen |
||||
Mesh count |
Wire dia.(mm) |
Mesh thickness(mm) |
||
warp |
weft |
warp |
weft |
|
72 |
15 |
0.45 |
0.55 |
1.75 |
120 |
15 |
0.35 |
0.45 |
1.25 |
132 |
17 |
0.32 |
0.45 |
1.20 |
150 |
17 |
0.30 |
0.45 |
1.20 |
152 |
24 |
0.27 |
0.40 |
1.05 |
152 |
30 |
0.25 |
0.30 |
1.00 |
170 |
17 |
0.27 |
0.45 |
1.17 |
260 |
40 |
0.15 |
0.25 |
0.65 |
Features:
With smooth surface, high hardness, working continuously, no deformation, high temperature resistance, corrosion resistance, flexible working with excellent filtering performance
Application In Auto Screen Changer for PP,PE,ABS,PS,PMMA and Other Materials
