|Place of Origin:||Hebei province ,china|
|Model Number:||SS wire mesh|
|Minimum Order Quantity:||1 SM2|
|Price:||Price based on quantity|
|Packaging Details:||Waterproof paper inside ,wooden case|
|Delivery Time:||stock always|
|Payment Terms:||L/C&TT& paypal|
The brief introduction for the stainless steel wire mesh fabric
Custom stainless Steel Woven Wire Mesh: we can provide custom wire mesh products to enhance your final product or help reduce your fabrication cost.
• Extra Long Rolls or Coils: Up to 800' with No Seams on selected items
• Extra Wide Widths: Up to 240" Wide is available on select items
• Selvage / Woven Edges
• Prototype Design Services available
• Special Wire Selection: (Cable Mesh, Plastic Coated Wires, and More)
Plain Weave Wire Mesh is the most commonly used and simplest wire cloth weave. Each shute wire is woven alternately over and under the warp wires through the cloth at 90 degree angles. This is a very common weave that can be produced quickly and economically. It has a wide range of applications.
Twilled Weave Wire Mesh is woven by passing each shute wire alternately over and under two warp wires. This type of weave about stainless steel woven wire mesh is commercially woven in items ranging from 150-635 mesh however it is also available in course and mid range mesh combinations.
Dutch Weave Wire Mesh is woven with a larger wire diameter in the warp direction and a relatively smaller wire in the shute direction. This weave of stainless steel woven wire mesh has great strength and is available in wide range of micron ranges. It is primarily used to filter a wide range of liquid and slurry products.
willed Dutch Weave Wire Mesh is a very strong stainless steel woven wire mesh product that is capable of very fine filtration. Shute wires are passed alternately over and under two warp wires forming a fine mesh. It has a wide range of filtration applications for gas and liquid applications.
Reverse Dutch Weave Wire Mesh is a very strong woven product. This mesh is ideal for making filter belts, and applications where fine filtration and great strength are required. This mesh is also made in reverse twill dutch and sometimes referred to as PZ and KPZ Mesh.
Five Heddle Weave Wire Mesh provides a rectangular opening. The unique design of this stainless steel woven wire mesh can assist increased drainage and flow properties. This mesh also has a smooth surface on one side.
