Stainless Steel Woven Wire Mesh
Material of Stainless Steel Woven Wire Mesh : SUS 302 304 304L 316 316L stainless steel wire, .
Weaving and characteristics ofStainless Steel Woven Wire Mesh:
Plain weave of Stainless Steel Woven Wire Mesh:
Each warp wire crosses alternately above and below each weft wire. Warp and weft wires generally have the same diameter
Twill weave of Stainless Steel Woven Wire Mesh:
Each weft wire passing alternately over two, and then under two successive warp wires and each warp wire passing alternately over two and under two successive weft wires.
Usage of Stainless Steel Woven Wire Mesh: Used in petroleum, chemical industry, mine, environment protection, food industry, paper-making, electronic industry, etc
Packing: Wrapped with moister-proof paper, then in wooden cases.
General specification of Stainless Steel Woven Wire Mesh:
The standard width: 0.6m-1.5m
The standard length: 30m/roll
The suitable wire diameter: 0.25mm-2.0mm
Mesh/inch: 3-400 mesh
Aperture: 6.27mm-0.0385mm
| Mesh |
Wire Dia. |
Aperture |
| Inch |
mm |
Inch |
mm |
| 1x1 |
0.08 |
2.03 |
0.92 |
23.37 |
| 2X2 |
0.063 |
1.6 |
0.437 |
11.1 |
| 3X3 |
0.054 |
1.37 |
0.279 |
7.09 |
| 5X5 |
0.041 |
1.04 |
0.159 |
4.04 |
| 8X8 |
0.028 |
0.71 |
0.097 |
2.46 |
| 10X10 |
0.025 |
0.64 |
0.075 |
1.91 |
| 12X12 |
0.02 |
0.508 |
0.063 |
1.6 |
| 14X14 |
0.02 |
0.508 |
0.051 |
1.3 |
| 16X16 |
0.018 |
0.457 |
0.0445 |
1.13 |
| 18X18 |
0.017 |
0.432 |
0.0386 |
0.98 |
| 20X20 |
0.016 |
0.406 |
0.034 |
0.86 |
| 30X30 |
0.012 |
0.305 |
0.0213 |
0.54 |
| 35X35 |
0.011 |
0.279 |
0.0176 |
0.45 |
| 40X40 |
0.01 |
0.254 |
0.015 |
0.38 |
| 60X60 |
0.007 |
0.178 |
0.0097 |
0.25 |
| 70X70 |
0.0065 |
0.165 |
0.0078 |
0.2 |
| 80X80 |
0.0055 |
0.14 |
0.007 |
0.18 |
| 100X100 |
0.004 |
0.102 |
0.006 |
0.15 |
| 110X110 |
0.004 |
0.1016 |
0.0051 |
0.1295 |
| 120X120 |
0.0037 |
0.094 |
0.0064 |
0.1168 |
| 150X150 |
0.0026 |
0.066 |
0.0041 |
0.1041 |
| 160X160 |
0.0025 |
0.0635 |
0.0038 |
0.0965 |
| 180X180 |
0.0023 |
0.0584 |
0.0033 |
0.0838 |
| 200X200 |
0.0021 |
0.0533 |
0.0029 |
0.0737 |
| 250X250 |
0.0016 |
0.0406 |
0.0024 |
0.061 |
| 300X300 |
0.0051 |
0.0381 |
0.0018 |
0.0457 |
| 400X400 |
0.001 |
0.0254 |
0.0015 |
0.37 |
| 500X500 |
0.001 |
0.0254 |
0.001 |
0.0254 |
| 635X635 |
0.0008 |
0.0203 |
0.0008 |
0.0203 |
