24x152mesh 127mm width x 10m length reverse dutch weave filter screen belt
SS302 OR SS 304
24x152 mesh
0.27x0.4mm
127mm width x 10m length
4.7KG/ROLL
Weaving Type: stainless steel woven on machine in holland /reverse dutch /concerse pattern arrange the hole opening
Stainless Steel Reverse Plain Dutch Weave Wire Mesh (RPD) is woven using two Sizes of wire. Smaller wires are used in the warp direction and are Woven with a larger shute wire. the smaller wires are woven tightly Together, providing a tight mesh for filtering. The larger wire provides Strength to the mesh. The primary uses of this wire cloth are Filtration and separation of liquid and slurry products.
Filter Belt Screens for screen changer :
: Stainless steel reversed dutch wire mesh, auto mesh belt Filter, reversed dutch wire mesh, reversed dutch mesh belt filter, auto Mesh belt filter
2.Features: smooth surface, high hardness, continuous net, no Deformation, high temperature resistance, corrosion resistance and Outstanding filtering performance.
3.Application: Suitable for filtering of plastic wire drawing machine, stretch film machine and coating machine.
Standard width: 97mm,98mm,100mm,127mm,130mm,133mm,150m,154mm,etc
Standard Length:10m/roll (standard)
Standard Material: SS 302,SS 304,SS 304A,SS 316,ETC
| Mesh counts |
Wire diameter(mm) |
Thickness(mm) |
Width(mm) |
| 54*15 |
0.45*0.6 |
1.75 |
50-800 |
| 72*15 |
0.45*0.55 |
1.7 |
50-800 |
| 132*17 |
0.23*0.45 |
1.2 |
50-1000 |
| 160*18 |
0.28*0.45 |
1.27 |
50-1000 |
| 200*40 |
0.17*0.27 |
0.7 |
50-1500 |
| 260*40 |
0.15*0.27 |
0.65 |
50-1500 |
| 300*40 |
0.15*0.27 |
0.65 |
50-1500 |
| 350*40 |
0.13*0.27 |
0.6 |
50-1500 |
Standard Specs:
- 48x10 mesh RDPW 400 nominal micron
- 72x15 mesh RDTW 250 nominal micron
- 132x16 mesh RDTW 200 nominal micron
- 152x30 mesh RDTW 115 nominal micron
- 250x40 mesh RDTW 75 nominal micron
A: Do you have stock or not?
Yes, we have a lot of stock( 800rolls stock always ) ,fast Delivery.
B: Do you accept small order -1 roll?
Yes, surely, 1 roll is no problem for us.
C: Do you offer free sample for our testing?
Yes, we surely offer free sample for your quality confirmation.
Details Show:
Filter Belt Screens for screen changer factory Features:
with Smooth surface, high hardness, working continuously, no deformation, High temperature resistance, corrosion resistance, flexible working with Excellent filtering performance.
Other sizes are avaliable according to clients'request.
Edge ofStainless Steel Extruder Filter Belt for ChangersFilter Belt Screens :
Applications of Stainless Steel Extruder Filter Belt for Changers:
High Tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry for PP, PE, ABS, PS, PMMA and other materials.
Packing of Filter Belt Screens
Waterproof paper on each roll + carton / wooden case
Shipping of Filter Belt Screens
by sea or by Air - Express, No problem for us.
Do you accept Paypal, west Union?
Yes It is ok for us,No problem.
