China 130 mesh 10mtr/roll Automatic Continous Belt Screen Filter Mesh
130 mesh -one type famouse screen changer belt mesh
--- the market need a lot of , we have always stock .
--RDTW ( reverse twill dutch woven )
---in Plastic using , can be round ,square shape , can be used in recycling after fire.
A LARGE OF STOCK FOR 10M/ROLL ,IF YOU NEED 20M PER ROLL WE ALSO CAN DO
Application of Automatic Continous Belt Screen Filter Mesh
** widely used in continuous screen changers. (automatic screen changers).
**Filter candles, vacuum filters and spring filters(as filter media in filtration process )
**Major in Plastic Extrusion,Melt Filtration and other plastic industry Filed for PP,PS,PVC,ABS,PE,PET etc.
Specification of Automatic Continous Belt Screen Filter Mesh
** Material : stainless steel 302,304,304A,316,316L
* *Size of width : 100mm to 1200mm. (such as 97mm,100mm,110mm,120mm.127mm,130mm,150mm)
** Size of Length : 10m/roll,20m/roll ( special ,available )
**Mesh Size : 48x10 mesh, 72x15 mesh, 132x14 mesh,132x16 mesh,132x18 mesh,152x24 mesh,160x16 mesh,160x24 mesh,160x25 mesh,228x36 mesh,250x40 mesh,260x40 mesh, 325x39 mesh,400x120 mesh etc.
** weaving Type : Reverse Dutch woven - reverse twill dutch & reverse plain dutch ,thicker warp wires and less weft wires
| 1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
| HB-Code |
Mesh |
Micron Retention |
Micron Retention |
Equation Factors for |
Tensile Strength |
Porosity theor. |
Weight |
Cloth Thickness |
| |
|
nominal |
absolute |
Permeability Performance |
Warp |
Weft |
|
|
|
| |
|
μm |
μm |
Y |
M |
N |
N |
% |
kg/m2 |
mm |
| RPD 15 |
720x150 |
15 |
16- 20 |
35.63 |
0.01726 |
240 |
400 |
45 |
0.65 |
0.15 |
| RPD 17 |
630x130 |
17 |
20- 24 |
30.95 |
0.02967 |
210 |
480 |
51 |
0.85 |
0.22 |
| RPD 25 |
600x100 |
25 |
34- 38 |
10.14 |
0.01751 |
205 |
425 |
56 |
0.80 |
0.23 |
| RPD 40 |
290x 75 |
40 |
53- 58 |
12.94 |
0.03460 |
540 |
700 |
51 |
1.55 |
0.40 |
| RPD 60 |
175x 50 |
60 |
67- 75 |
8.29 |
0.03479 |
570 |
1200 |
47 |
2.40 |
0.57 |
| TRD 75 |
400x120 |
75 |
75- 80 |
4.00 |
0.00520 |
360 |
230 |
62 |
0.73 |
0.24 |
| RPD 80 |
130x 35 |
80 |
95-105 |
8.25 |
0.01614 |
860 |
1250 |
49 |
3.10 |
0.77 |
| RPD 85 |
175x 37 |
85 |
100-106 |
3.81 |
0.00255 |
780 |
720 |
54 |
2.10 |
0.57 |
| RPD 90 |
170x 40 |
90 |
106-118 |
4.03 |
0.01569 |
890 |
770 |
54 |
2.10 |
0.57 |
| TRD 125 |
260x 40 |
125 |
112-125 |
1.12 |
0.16700 |
2220 |
580 |
54 |
2.25 |
0.62 |
| RPD 400 |
84x 14 |
|
450-530 |
0.33 |
0.01028 |
1630 |
1160 |
62 |
3.50 |
1.15 |
| TRD 400 |
132x 17 |
|
400-450 |
1.00 |
0.01686 |
4500 |
760 |
57 |
4.65 |
1.35 |
| RPD 500 |
80x 14 |
|
560-630 |
0.10 |
0.01123 |
1550 |
1160 |
64 |
3.40 |
1.18 |
| TRD 500 |
72x 15 |
|
500-600 |
0.02 |
0.01567 |
5330 |
810 |
57 |
6.35 |
1.85 |
Feature of Automatic Continous Belt Screen Filter Mesh:
**Non stop -continous
**anti -corrosion
** Fine filtration -special woven type
Packing of Automatic Continous Belt Screen Filter Mesh:
-- waterproof paper + Label mark
--film+waterpoof paper + Label mark
--carton box ,or wooden case + shipping mark
