100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer

100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer

    • 100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer
    • 100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer
    • 100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer
    • 100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer
    • 100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer
    • 100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer
  • 100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer

    Product Details:

    Place of Origin: Hebei,china
    Brand Name: XKh
    Certification: iso,ce
    Model Number: continuous filter belt for scren changer in plastic extruder machine

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: Price based on quantity
    Packaging Details: film+waterproof paper , carton or wooden case is available
    Delivery Time: ready sock in 3 days
    Payment Terms: L/C,TT
    Supply Ability: 10000rolls /month
    Contact Now
    Detailed Product Description
    Name: Continous Screen Changer Using Stainless Steel Conveyor Belt Width: 97mm,127mm,130mm,150mm Etc
    Length: 10m/roll ,15m/roll ,20m/roll ,etc MOQ: 1 Roll
    Mesh: 72x15,152x24,132x17,260x40,, 160 Mesh , 130 Mesh ,160 Mesh , 200 Mesh , Etc Function: Belt Mesh Filter Belt Used In Non-stop Screen Changer
    Fair Attend: China West Rubber And Plastic In CQ City Weaving Type: Twill /Plain Reverse Dutch Belt

    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer


    According to local differences and usage are also known as: reverse dutch belt netting (also called Dutch/holland cloth)


    Material: stainless steel iron wire is common ,like ss202 ,304,316 ,sometimes copper and nickel wire available ,also weave according to customer's request for special material

    Weaving Type : Reverse Dutch
    Features: mesh smooth, high hardness, continuous network, no deformation, high temperature.
    Specifications: General length of 10 meters/20meters long,
    width :40mm-110mm,common width :97mm,120mm,127mm,130mm,150mm,etc
    mesh :40 mesh -350 mesh, common mesh : 48x10 mesh, 72x15 mesh, 132x14 mesh,132x16 mesh,132x18 mesh,152x24 mesh,160x16 mesh,160x24 mesh,160x25 mesh,228x36 mesh,250x40 mesh,260x40 mesh, 325x39 mesh,400x120 mesh etc.also people call 100mesh,120mesh,130mesh,160mesh,180mesh,200mesh,etc

    Uses: Applicable to the Austrian Lenzing equipment and Germany, Japan and other countries of the wire drawing machine, casting film machine, coating machine filter. Domestic equipment: Lanfei 90 presses, Changzhou Hengli presses, Yantai presses, etc., are widely used in such as plastic woven bags, plastic film, aerospace, petroleum, chemical, chemical fiber, machinery, plastic products, research and transportation industry. Plastic extruder with automatic belt filter, plastic melt filter, press belt filter. Products work fine, often with the filter equipment exported to Southeast Asia, Britain, Germany, Japan, the United States, South Africa, Indonesia, Thailand and other countries and regions.



    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer

    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer



    Basic specifications



    Mesh

    Wire Dai.(mm)

    Thickness(mm)

    Width(cm)

    45x15

    0.45x0.6

     1.75

    9.7-28

    48X10

    0.50X0.50

    3.6kg/sq.m

    9.7-28

    72x15

    0.45x0.55

    1.7

    9.7-28

    90X17

    0.23X0.55

    2.48kg/sq.m

    9.7-28

    110X17

    0.23X0.55

    2.6kg/sq.m

    9.7-28

    110X21

    0.23X0.35

    2.0kg/sq.m

    9.7-28

    120x16

    0.35x0.45

     1.36

    9.7-28

    132x17

    0. 3x0.45

    1.3

    9.7-28

    152x24

    0.3x0.40

    1.2

    9.7-28

    160x18

    0.28x0.45

     1.27

    8-85

    200x40

    0.15x0.27

    0.7

    8-130

    260x40

    0.15 x0.27

     0.65

    8-130

    300x40

    0.15 x0.27

     0.65

    8-130

    360x40

    0.13 x0.27

    0.6

    8-130

     Special specification we can produce according to customers' requirements.



    A : Do you have stock or not ?



    Yes , we have a lot of stock(  800rolls stock always )  ,fast delivery .



    B:  Do you accept small order -1 roll ?



    Yes, surely , 1 roll is no problem for us .



    C : Do you offer free sample for our testing ?



    Yes , we surely offer free sample for your quality confirmation .



    SS302 Belt filter mesh for screen changer Features:

    With smooth surface, high hardness, working continuously, no deformation, high temperature resistance, corrosion resistance, flexible working with excellent filtering performance.



    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer



    Edge of SS302 Belt filter mesh for screen changer:



    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer



    Applications of SS302 Belt filter mesh for screen changer:







    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer



    Packing of SS302 Belt filter mesh for screen changer:



    Waterproof paper on each roll + carton / wooden case



    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer

    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer

    Shipping  of SS302 Belt filter mesh for screen changer:

     By sea or By Air - Express , No problem for us .

     Do you accept Paypal , west Union ?

      Yes It is ok for us ,No problem .





    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer



    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer

    100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer100mesh SS302 97mm 127mm 130mm belt filter mesh for screen changer
