    Product Details:

    Place of Origin: Hebei,china
    Brand Name: XKh
    Certification: iso,ce
    Model Number: 3D eps panel

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: US $20 - 80 / Piece
    Packaging Details: Packing of 3D wire mesh panel: in bulk on pallet Or as per request
    Delivery Time: Shipped in 5 days after payment
    Payment Terms: L/C,TT
    Supply Ability: 1000 Piece/Pieces per Day
    Contact Now
    Detailed Product Description
    Products: 3D EPS PANEL Material: Low-Carbon Iron Wire, Galvanized Iron Wire With EPS
    Wire Gauge: 2mm-4mm Galvanized Or Non-galvanized Hole Size: 50x50mm,75mmx75mm,100mmx100mm
    Truss Wire Diameter:: 2.2-2.8mm Width: 1200mm,1220mm
    Panel Length: 2400mm,3000mm,6000mm ,etc EPS Insulation Core: 50mm-100mm
    Usage: An Be Used For The Walls,roof, Floor, And So On

                       3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall



    Material: low carbon steel wire,stainless steel wire

    Type : Two Type :w-wire type( drawing 1 ) & cut wire type( drawing 2) :

    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall



    Specification :



    Mesh wire: 2-2.8mm galvanized or non galvanized.
    Mesh opening(mm) : 50 x 50, 75 x 75 and 100 x 100.
    Truss wire: 2-2.8mm galvanized or non galvanized.
    Panel: 1220mm.
    Panel length: 2400mm, 3000mm and 6000mm.
    EPS Insulation Core: 50-100mm.

    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall





    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall

    2.The Picture show of 3D Ploystyrene combined Board :

    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall



    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall



    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall



    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall



                                            USED For WALL - FIRMED STRUCTURE



    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall

    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall

    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall



    The Packing & Shipping of 3D Ploystyrene combined Board :

    • 3D PANEL - BECASUE BIG SIZE -REASONABLE CONTAINER -40 FEET ( 270 PIECES AROUND )
    • BULK OR PALLET OR DO AS PER CUSTOMER



    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall



    6.Benefits of 3D Ploystyrene combined Board ::

    • Thermal Insulation
      The EPS squeezing foaming polystyrene, a famous material of thermal insulation, is widely used to reduces the loss of heat in construction. Whether in hot summer or cold winter, 3D panels do help room temperature remain at a comfortable degree.
    • Fireproofing
      It has passed the 120 minutes fireproofing test by National Construction Institute and also been approved as the fireproofing material for internal & external construction stuffs.
    • Moisture proofing
      As we have used the high performance foaming polystyrene 100m/m of water absorption, it shows an excellent prevention against the condensation on the wall. (As for the usage of external wall, the exterior on the external wall needs the waterproofing mortar.)
    • Soundproofing
      With regard to sound insulation, 3d panel shows a distinguished feature of soundproofing among other materials. Besides, it shows a stronger capability of sound proofing with both sides plasterboard.
    • Lightweight
      Equal volumes of 3d panels and masonry wall, the former only weighs a quarter of the latter. Using a 3d panel can significantly alleviates the fixed load of structure and also highly be recommended for the enlargement of old buildings.
    • Structure
      It is used for every construction like residence and apartment. Especially, it is highly recommended the higher the building is and the longer its span is.
    • Variety
      The panels can be designed in a varied forms without any professional knowledge, and fits for the round-typed materials as increasing 10% indoor space compared with masonry structure.
    • Economical Efficiency
      As a standardized factory product, 3d panels are easy to install, and allows us to execute the masonry, insulation, plastering at the same time, which surely reduces the construction time down to a third.
    • Shortening of Construction Time
      Easy installation of 3d panels can reduce the cost of labor and construction expenses.



    Other 3d panel :

    3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall3D Welded EPS Panel,EVG 3D Panel System,3D Wire Mesh Block Panel Wall
