150 Micron Brass Screen Fabric #100 Mesh 0.1mm Wire Dia made in china
Specification:
|
Material
|
Brass Wire (Cu: 65% , Zn:35%)
|
|
Wire Diameter (D)
|
0.1mm (0.0039”)
|
|
Aperture (L)
|
0.15mm (0.006”)
|
|
Open Area
|
41.69%
|
|
Weight
|
0.56 kgs/m2
|
|
Roll Width
|
1.0m,1.2m,1.5m or as customers’request.
|
|
Roll Length
|
30m, 60m
|
Production range of brass screen fabric:
(1) wire diameter: 0.04-1mm
(2) mesh counts: 3-200 mesh
(3) common roll width:1m, 1.2m, 1.5m, 1.8m, 2m
(4) common roll length:30m, 50m, 100m
Other size :
|
Mesh
|
Wire Dia. (MM) |
Opening(mm) |
| SWG |
mm |
inch |
| 6mesh |
22 |
0.711 |
0.028 |
3.522 |
| 8mesh |
23 |
0.610 |
0.024 |
2.565 |
| 10mesh |
25 |
0.508 |
0.020 |
2.032 |
| 12mesh |
26 |
0.457 |
0.018 |
1.660 |
| 14mesh |
27 |
0.417 |
0.016 |
1.397 |
| 16mesh |
29 |
0.345 |
0.014 |
1.243 |
| 18mesh |
30 |
0.315 |
0.012 |
1.096 |
| 20mesh |
30 |
0.315 |
0.0124 |
0.955 |
| 22mesh |
30 |
0.315 |
0.0124 |
0.840 |
| 24mesh |
30 |
0.315 |
0.0124 |
0.743 |
| 26mesh |
31 |
0.295 |
0.0116 |
0.682 |
| 28mesh |
31 |
0.295 |
0.0116 |
0.612 |
| 30mesh |
32 |
0.247 |
0.011 |
0.573 |
| 32mesh |
33 |
0.254 |
0.010 |
0.540 |
| 34mesh |
34 |
0.234 |
0.0092 |
0.513 |
| 36mesh |
34 |
0.234 |
0.0092 |
0.472 |
| 38mesh |
35 |
0.213 |
0.0084 |
0.455 |
| 40mesh |
36 |
0.193 |
0.0076 |
0.442 |
| 42mesh |
36 |
0.193 |
0.0076 |
0.412 |
| 44mesh |
37 |
0.173 |
0.0068 |
0.404 |
| 46mesh |
37 |
0.173 |
0.0068 |
0.379 |
| 48mesh |
37 |
0.173 |
0.0068 |
0.356 |
| 50mesh |
37 |
0.173 |
0.0068 |
0.335 |
| 60X50mesh |
36 |
0.193 |
0.0076 |
- |
| 60X50mesh |
37 |
0.173 |
0.0068 |
- |
| 60mesh |
37 |
0.173 |
0.0068 |
0.250 |
| 70mesh |
39 |
0.132 |
0.0052 |
0.231 |
| 80mesh |
40 |
0.122 |
0.0048 |
0.196 |
| 90mesh |
41 |
0.112 |
0.0044 |
0.170 |
| 100mesh |
42 |
0.012 |
0.004 |
0.152 |
| 120X108mesh |
43 |
0.091 |
0.0036 |
- |
| 120mesh |
44 |
0.081 |
0.0032 |
0.131 |
| 140mesh |
46 |
0.061 |
0.0024 |
0.120 |
| 150mesh |
46 |
0.061 |
0.0024 |
0.108 |
| 160mesh |
46 |
0.061 |
0.0024 |
0.098 |
| 180mesh |
47 |
0.051 |
0.002 |
0.090 |
| 200mesh |
47 |
0.051 |
0.002 |
0.076 |
Characteristics:
(1) non-magnetic, wear resistance
(2) acid and alkali resistance, good ductility
(3)good conductivity, good heat transfer performance
Application:
(1) screening a variety of particles,powder, porcelain clay, glass,the radio signal shielding.
(2) filtering liquid and gas,chemicals.
(3)for electronic equipment , customs, aviation and space, information industry, machinery, fi
nance etc.
Packaging & Shipping
Packing Of Brass Wire Mesh:
150 micron brass woven wire mesh use moisture-proof packing and anti-extrusion packing.150micron Brass woven wire mesh is wound around flat and dry mandrel,inside with moisture-proof paper or other packaging
material and outside with wooden cases or wooden pallets
