Galvanized welded gabion in size of (3x1.5x0.3)m & (3x1.5x0.6) to Afghanistan
Gabion Example size :
The wire of gabion 4mm
Gabion Size : 3X1.5X0.3m
Brief introduction
Boxes are full of stones for protecting bank of river!
Including: welded gabion box and heavy hexagonal gabion box
Surface treatment: galvanized, high zinc coating wire, galfan wire(Zn-Al alloy wire), PVC coated, PVC soaking
Size: customer-made
Heavy hexagonal gabion box:
PVC coated: diametre ranges from 3.0-4.0mm
Galvanized: diameter ranges from 2.0-4.0mm
Wire of the outside frame edge is thicker than the one used for hexagonal wire netting
Aperture: 60x80mm 80x100mm 80x120mm 100x120mm 100x150mm 120x150mm
Size according to your needs
Welded gabion box:
General aperture: 50x50mm 75x75mm 50x100mm 50x75mm
Front and back panels, a bottom plate and a baffle plate after welding forming are assembled by spiral binding wires, compressed and then packaged together with a mesh cover.
| Material |
Steel Wire |
| Surface Treatment |
Zinc Coated Welded Gabion(Common hot dipped galvanized or Heavy zinc coating ) |
| PVC Coated Welded Gabion |
| Zinc aluminum alloy Coated Welded Gabion(5% aluminum or 10% aluminum) |
| ASTM Standard |
ASTM A 856 |
| ASTM A 641 |
Kindly note :
Heavy hexagonal gabion box:
PVC coated: diametre ranges from 3.0-4.0mm
Galvanized: diameter ranges from 2.0-4.0mm
Wire of the outside frame edge is thicker than the one used for hexagonal wire netting
Aperture: 60x80mm 80x100mm 80x120mm 100x120mm 100x150mm 120x150mm
SQUARE HOLE :
| Welded gabion unit |
|
| Wire dia |
3.0-5.0mm |
| Size |
1*1*1m |
| 2*1*1m |
| 3*1*1m |
| 4*1*1m |
| 5*1*1m |
| Finish |
Hot dipped galvanized, galfan coated |
| Hole |
50*50, 75*75, 100*100 etc
|
RECTANGEL HOLE :
| Aperture(cm) |
Wire diameter(mm) |
Dimension of gabion box(m) |
| 5×7 |
2.4 |
0.5×0.5×1 |
| 5×7 |
2.7 |
1×1×1 |
| 5×10 |
3.5 |
1×1×2 |
Below is our workshop:-Gabion mesh panel ready
SPIRALS Hooks /Stiffeners Mesh panel
Application
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil.
Protection engineering of seaside area.
