''WHY CHOOSE OUR FILTER SCREEN''
--100% Stainless Steel With 304 & 316 Grade
--Extensive Products Range
--Widest Range Of Size (4 Mesh To 1500 Mesh)
--Ready-to-use (5mm To 800mm Diameter)
--Ready Availability
--World-Class Quality With Smooth Cutting Burr Free Edge
--Comprehensive Raw Material Inventory
--Specialized Cutting Dies And Tool For High Precision
--High Pressure And High Temperature Withstanding Capabilities.
Stainless Steel Filter Belt For Automatic Continuous Screen Changer
1.Material:SS302#,SS304#,SS316L# etc.
2.Mesh:72/15,132/17,152/24,152/30,260/40,etc.
3.Length of Wire Mesh Filter Belt:10mtrs or 20mtrs
Width of Wire Mesh Filter Belt:50mm-300mm
|
Stainless Steel Filter Belt For Screen Changer
|
|
Mesh count
|
Wire dia.(mm)
|
Mesh thickness(mm)
|
|
warp
|
weft
|
warp
|
weft
|
|
72
|
15
|
0.45
|
0.55
|
1.75
|
|
120
|
15
|
0.35
|
0.45
|
1.25
|
|
132
|
17
|
0.32
|
0.45
|
1.20
|
|
150
|
17
|
0.30
|
0.45
|
1.20
|
|
152
|
24
|
0.27
|
0.40
|
1.05
|
|
152
|
30
|
0.25
|
0.30
|
1.00
|
|
170
|
17
|
0.27
|
0.45
|
1.17
|
|
260
|
40
|
0.15
|
0.25
|
0.65
|
Features:
With smooth surface, high hardness, working continuously, no deformation, high temperature resistance, corrosion resistance, flexible working with excellent filtering performance
Application In Auto Screen Changer for Woven Bags :
