    Product Details:

    Place of Origin: Hebei ,China
    Brand Name: Plastic Extruder Line Use Reverse Dutch Weave Wire Mesh
    Certification: ce,sgs
    Model Number: Plastic Extruder Line Use Reverse Dutch Weave Wire Mesh

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 roll
    Price: 10 usd-45usd/square meter
    Packaging Details: Waterproof paper or up to customer's requirement
    Delivery Time: stock always
    Payment Terms: TT,LC,PAYPAL ,WEST UNION ,ETC
    Supply Ability: 80000 Roll/Rolls per Year
    Contact Now
    Detailed Product Description
    Item: Reverse Dutch Wire Mesh Belt Width: 97mm,127mm,130mm,150mm ,etc
    Material: 302,304,304A,316 MOQ: 1 Roll

    SS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in China

    SS Auto Continuous Screen is woven using two sizes of wire. Smaller wires are used in the warp direction and are woven with a larger shute wire. The smaller wires are woven tightly together, providing a tight mesh for filtering. The larger wire provides strength to the mesh. The primary uses of this wire cloth are filtration and separation of liquid and slurry products.

    SS Auto Continuous Screen combines Dutch and twill weaving to provide a fine mesh filtering cloth. The weaving process allows for the use of very fine wires, producing filtering mesh for gas and liquid applications. We also provide Herringbone and Broken Pattern Reverse Twill Dutch Weave Products.

    Weave types of SS Auto Continuous Screen :Reverse Plain Dutch Weave and Reverse Twill Dutch Weave.

    Materials of Automatic stainless steel filter belt -Reverse Dutch Weave(Reverse Dutch Weave Wire Mesh): Reverse Dutch Weave Wire Mesh is made by using stainless steel wire 304,304L,316,316L 904 904L 310 310s 410 430 etc..

    feature of SS Auto Continuous Screen :

    • High Tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry.
    • Rubbed Edges after slitting to help with tracking for Auto-Screen changers.
    • Plasma and laser cut parts to help prevent edges wire fraying.
    • 100% Inspection of Wire Cloth for critical applications such as sand screens and aerospace applications.

    We offer a wide range of metals and alloys to provide the best material or combination of materials for the filter mesh. Contact us today for more information or a detailed quote.

    Application of Reverse dutch wire mesh:

    • Suitable for plastic wire drawing machine, stretch film machine, coating machine filters, such as plastic woven bag, plastic film.
    • Used for plastic recycling filter, otherwise wafer type, square type, single or multi-layer molding machine filter.
    Size

     Standard Specs

    • 48x10 mesh RDPW 400 nominal micron
    • 72x15 mesh RDTW 250 nominal micron
    • 132x16 mesh RDTW 200 nominal micron
    • 152x30 mesh RDTW 115 nominal micron
    •  250x40 mesh RDTW 75 nominal micron

    SS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in China

    A : Do you have stock or not ?



    Yes , we have a lot of stock(  800rolls stock always )  ,fast delivery .



    B:  Do you accept small order -1 roll ?



    Yes, surely , 1 roll is no problem for us .



    C : Do you offer free sample for our testing ?



    Yes , we surely offer free sample for your quality confirmation .





    Continuous blet  for plastic extruder machine Features:

    With smooth surface, high hardness, working continuously, no deformation, high temperature resistance, corrosion resistance, flexible working with excellent filtering performance.



    SS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in China



    Continuous automatic filter belt

    Mesh/inch

    Wire Dia.(mm)

    Width(mm)

    Length/Roll(m)

    72/15

    0.45/0.55

    97---400

    10/20

    120/15

    0.35/0.45

    97---400

    10/20

    132/17

    0.32/0.45

    97---400

    10/20

    150/17

    0.3/0.45

    97---400

    10/20

    152/24

    0.27/0.4

    97---400

    10/20

    170/17

    0.27/0.45

    97---400

    10/20

    180/18

    0.27/0.45

    97---400

    10/20

    200/40

    0.17/0.27

    97---400

    10/20

    260/40

    0.15/0.25

    97---400

    10/20



    Other sizes are avaliable according to clients'request.



    Edge of SS Auto continous Screen:



    SS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in China



    Applications of SS Auto continous Screen:







    SS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in China

    High Tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry for PP, PE, ABS, PS, PMMA and other materials.

    Stainless Steel Reverse Plain Dutch Weave Wire Mesh (RPD) is woven using two sizes of wire. Smaller wires are used in the warp direction and are woven with a larger shute wire. The smaller wires are woven tightly together, providing a tight mesh for filtering. The larger wire provides strength to the mesh. The primary uses of this wire cloth are filtration and separation of liquid and slurry products.



    Packing of SS Auto continous Screen:



    Waterproof paper on each roll + carton / wooden case



    SS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in ChinaSS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in China

    SS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in ChinaSS RDW Woven  Wire Cloth Filter Belts For Continuous Screen Changers made in China

    Shipping  of SS Auto continous Screen:

     By sea or By Air - Express , No problem for us .
