24x152mesh 150mm width x 10m length reverse dutch weave filter screen belt

24x152mesh 150mm width x 10m length reverse dutch weave filter screen belt

    • 24x152mesh 150mm width x 10m length reverse dutch weave filter screen belt
    • 24x152mesh 150mm width x 10m length reverse dutch weave filter screen belt
    • 24x152mesh 150mm width x 10m length reverse dutch weave filter screen belt
    • 24x152mesh 150mm width x 10m length reverse dutch weave filter screen belt
  • 24x152mesh 150mm width x 10m length reverse dutch weave filter screen belt

    Product Details:

    Place of Origin: Hebei ,China
    Brand Name: Plastic Extruder Line Use Reverse Dutch Weave Wire Mesh
    Certification: ce,sgs
    Model Number: Plastic Extruder Line Use Reverse Dutch Weave Wire Mesh

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 roll
    Price: 10 usd-45usd/square meter
    Packaging Details: Waterproof paper or up to customer's requirement
    Delivery Time: stock always
    Payment Terms: TT,LC,PAYPAL ,WEST UNION ,ETC
    Supply Ability: 80000 Roll/Rolls per Year
    Contact Now
    Detailed Product Description
    NAME: 18X160 Mesh 150mm Width X 10m Length Reverse Dutch Weave Filter Screen Belt Application: For Screen Changer
    Width: 97mm,100mm,110mm,127mm,130mm,150mm,etc Length: 10m/20m



    24x152mesh 150mm width x 10m length reverse dutch weave filter screen belt



    SS302 OR SS 304

    24x152 mesh

    0.27x0.4mm

    150mm width x 10m length

    5.7KG/ROLL

    Filament Extruder Using Stainless Steel Screen Filter Screen Changer Band

    Weaving Type: stainless steel woven on machine in holland /reverse dutch /concerse pattern arrange the hole opening

    Stainless Steel Reverse Plain Dutch Weave Wire Mesh (RPD) is woven using two Sizes of wire. Smaller wires are used in the warp direction and are Woven with a larger shute wire. the smaller wires are woven tightly Together, providing a tight mesh for filtering. The larger wire provides Strength to the mesh. The primary uses of this wire cloth are Filtration and separation of liquid and
    slurry products.





    97mm 100mm130mm width Stainless Steel Reverse Dutch Wire Mesh

    Filter Belt Screens for screen changer :

    : Stainless steel reversed dutch wire mesh, auto mesh belt Filter, reversed dutch wire mesh, reversed dutch mesh belt filter, auto Mesh belt filter

    2.Features: smooth surface, high hardness, continuous net, no Deformation, high temperature resistance, corrosion resistance and Outstanding filtering performance.

    3.Application: Suitable for filtering of plastic wire drawing machine, stretch film machine and coating machine.



    Standard width: 97mm,98mm,100mm,127mm,130mm,133mm,150m,154mm,etc
    Standard Length:10m/roll (standard)
    Standard Material: SS 302,SS 304,SS 304A,SS 316,ETC



    Mesh counts Wire diameter(mm) Thickness(mm) Width(mm)
    54*15 0.45*0.6 1.75 50-800
    72*15 0.45*0.55 1.7 50-800
    132*17 0.23*0.45 1.2 50-1000
    160*18 0.28*0.45 1.27 50-1000
    200*40 0.17*0.27 0.7 50-1500
    260*40 0.15*0.27 0.65 50-1500
    300*40 0.15*0.27 0.65 50-1500
    350*40 0.13*0.27 0.6 50-1500






    Standard Specs:

    • 48x10 mesh RDPW 400 nominal micron
    • 72x15 mesh RDTW 250 nominal micron
    • 132x16 mesh RDTW 200 nominal micron
    • 152x30 mesh RDTW 115 nominal micron
    • 250x40 mesh RDTW 75 nominal micron



    A: Do you have stock or not?



    Yes, we have a lot of stock( 800rolls stock always ) ,fast Delivery.



    B: Do you accept small order -1 roll?



    Yes, surely, 1 roll is no problem for us.



    C: Do you offer free sample for our testing?



    Yes, we surely offer free sample for your quality confirmation.


    Details Show:

    Plastic Extrusion Filter Mesh Band for non stop screen changerPlastic Extrusion Filter Mesh Band for non stop screen changer
    Plastic Extrusion Filter Mesh Band for non stop screen changerPlastic Extrusion Filter Mesh Band for non stop screen changer

    Filter Belt Screens for screen changer factory Features:

    with Smooth surface, high hardness, working continuously, no deformation, High temperature resistance, corrosion resistance, flexible working with Excellent filtering performance.
    Stainless Steel Continuous Screen Belt for Circular Looms made in China



    Other sizes are avaliable according to clients'request.



    Edge ofStainless Steel Extruder Filter Belt for ChangersFilter Belt Screens :
    Stainless Steel Continuous Screen Belt for Circular Looms made in China

    Applications of Stainless Steel Extruder Filter Belt for Changers:


    Plastic Extrusion Filter Mesh Band for non stop screen changer

    High Tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry for PP, PE, ABS, PS, PMMA and other materials.





    Packing of Filter Belt Screens



    Waterproof paper on each roll + carton / wooden case
    Stainless Steel Continuous Screen Belt for Circular Looms made in China

    Plastic Extrusion Filter Mesh Band for non stop screen changer
    Plastic Extrusion Filter Mesh Band for non stop screen changer

    Shipping of Filter Belt Screens

    by sea or by Air - Express, No problem for us.

    Do you accept Paypal, west Union?

    Yes It is ok for us,No problem.

    Plastic Extrusion Filter Mesh Band for non stop screen changer
