304 Continuous automatic belt type filter screen

304 Continuous automatic belt type filter screen

304 Continuous automatic belt type filter screen

Product Details:

Place of Origin: Hebei province ,china
Brand Name: HIghui
Certification: ISO9001:2000,CE,SGS,COC
Model Number: BELT

Payment & Shipping Terms:

Minimum Order Quantity: 1 roll
Price: Price based on quantity
Packaging Details: Waterproof paper or up to customer's requirement
Delivery Time: stock always
Payment Terms: L/C&TT& paypal
Contact Now
Detailed Product Description
Usage: Screen Changer

304 Continuous automatic belt filter screen

Brief introduct

Continuous automatic belt filter screen also called reverse dutch wire mesh, Made of high quality high strength stainless steel wire excellent production technology, advanced equipment, has excellent filtering performance.

The weft wires are of greater diameter than the warp wires, and consequently the warp mesh count is greater than the weft mesh count. This cloth is extremely strong, is easily cleaned and has a high flow rate.

Characteristics

1. With smooth surface

2.High hardness

4.High temperature resistance,  good low temperature resistance

5.Corrosion resistance

6.Filtering performance is stable

7.Can reach 20 horsepower

8.Has excellent filtering performance

9.Through the machine very flexibility

10.Good filtering precision, load high strength,etc

Application

1.Widely used in aerospace, petroleum, chemical, chemical fiber, machinery, plastic products, research and transportation and other industries
2.Applicable to the Austrian lenzing equipment and Germany, Japan and other countries of the wire drawing machine, stretch film machine, coating machine filters.Domestic equipment: LanFei molding machine 90, changzhou hengli molding machine, yantai production molding machine, etc.Often exported to southeast Asia, UK, Germany, Japan, the United States, South Africa, Indonesia, Thailand and other countries and regions.



Specification

Material: 302,304,316stainless steel

Weave type:Plain dutch,twill duch

Width:Max:50cm

Common length:10m/roll



Mesh/inch

Wire Dia.(mm)

Width(mm)

Length/Roll(m)

72/15

0.45/0.55

97---400

10/20

120/15

0.35/0.45

97---400

10/20

132/17

0.32/0.45

97---400

10/20

150/17

0.3/0.45

97---400

10/20

152/24

0.27/04

97---400

10/20

170/17

0.27/0.45

97-400

10/20

180/18

0.27/0.45

97-400

10/20

200/40

0.17/0.27

97---400

10/20

260/40

0.15/0.25

97---400

10/20
