Dutch Woven Wire Mesh - Factory direct selling

Product Details:

Place of Origin:	Hebei,china
Brand Name:	XKh
Certification:	iso,ce
Model Number:	SS wire mesh

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	Price based on quantity
Packaging Details:	Waterproof paper inside ,wooden case
Delivery Time:	stock always
Payment Terms:	L/C,TT

Contact Now

Detailed Product Description

The Stainless Steel Filtration mesh is also known as Stainless Steel Dutch woven Filter cloth or Stainless Steel Dutch woven Filtration mesh

The filter mesh must be keep the very good mesh can filtering separation well, we used the imports reeds of Germany for woven, the mesh or hole is smooth and beautiful

Materials:
Stainless Steel Wire Mesh (Wire Cloth), SUS302 SUS304 SUS304L SUS316 SUS316L
Nickel Wire Mesh (Wire Cloth) Dutch Woven Wire Cloth
Brass Wire Mesh (Wire Cloth) Dutch Woven Wire Cloth
Red Red Copper Wire Mesh (Wire Cloth) Dutch Woven Wire Cloth
Phosphor Bronze Wire Mesh (Wire Cloth) Dutch Woven Wire Cloth
Mild Steel Wire Mesh (Wire Cloth) Dutch Woven Wire Cloth
Special Alloy Wire Mesh (Wire Cloth) Dutch Woven Wire Cloth

Weaving Types:
Wire Mesh Filter Cloth-Plain Dutch Weave
Wire Mesh Filter Cloth-Twill Dutch Weave
Wire Mesh Filter Cloth-Reverse Dutch Weave
Wire Mesh Filter Cloth-Five-Heddle Weave

Property: This kind of woven wire mesh offers good wear-resistance, heat-resistance, acid-resistance and corrosion resistance.

Usage: Dutch Woven Wire Cloth are extensively utilized as filter fittings for chemical industry, medicine, petroleum, telecom-communication, scientific research units, due to its stable and fine filtration capability
Usage: Dutch Woven Wire Cloth are extensively utilized as filter fittings for chemical industry, medicine, petroleum, telecom-communication, scientific research units, due to its stable and fine filtration capability

Wire Mesh Filter Cloth Dutch Woven
Gauge No.	Mesh/Inch(Warp x Weft)	Wire Diameter (Warp x Weft)	Reference Aperture (um)	Weight/sq (kg)
32#	8 x 62	0.63mm x 0.45mm	300	5.42
40#	10 x 79	0.50mm x 0.355mm	250	3.16
48#	12 x 64	0.58mm x 0.40mm	280	2.9
55#	14 x 88	0.40mm x 0.30mm	180	2.54
76#	19 x 140	0.315mm x 0.20mm	140	1.88
80#	20 x300	0.35mm x 0.20mm	-	3.6
95#	24 x 110	0.355mm x 0.25mm	120	2.45
100#	25 x 140	0.28mm x 0.20mm	100	1.95
120#	30 x 150	0.25mm x 0.18mm	80	1.68
140#	35 x 175	0.224mm x 0.16mm	71	1.52
160#	40 x 200	0.20mm x 0.14mm	60	1.4
180#	45 x 250	0.16mm x 0.112mm	56	1.09
200#	50 x 250	0.14mm x 0.11mm	53	1.04
220#	55.5 x 280	0.14mm x 0.10mm	50	0.92
240#	65 x 330	0.11mm x 0.08mm	36	0.71
280#(1)	70 x 350	0.11mm x 0.08mm	35	0.72
280#(2)	70 x 385	0.11mm x 0.07mm	32	0.75
300#	78 x 700	0.11mm x 0.08mm	30	1.39
315#(1)	80 x 400	0.10mm x 0.065mm	40	0.62
315#(2)	80 x 600	0.10mm x 0.06mm	-	-
315#(3)	80 x 800	0.15mm x 0.04mm	-	-
320#	81 x 780	0.10mm x 0.07mm	30	1.22
354#	90 x 550	0.12mm x 0.05	-	-
Roll width: 1-1.6m

Wire Mesh Filter Cloth Dutch Woven
Gauge No.	Mesh/Inch(Warp x Weft)	Wire Diameter	Reference Aperture	Weight/sq
Gauge No.	Mesh/Inch(Warp x Weft)	(Warp x Weft)	(um)	(kg)
360#	91 x 787	0.10mm x 0.07	25	1.24
400#	101 x 900	0.10mm x 0.063	20	1.22
472#	120 x 400	0.10mm x 0.075	-	-
500#	127 x 1100	0.07mm x 0.05	17	0.81
630#	160 x 1500	0.063mm x 0.04	15	0.62
650#(1)	165 x 400	0.071mm x 0.06	-	-
650#(2)	165 x 600	0.071mm x 0.05	-	-
650#(3)	165 x 800	0.071mm x 0.05	25	-
650#(4)	165 x 1100	0.071mm x 0.045	-	-
650#(5)	165 x 1400	0.071mm x 0.04	16	0.76
685#	174 x 1700	0.063mm x 0.032	13	0.61
787#(1)	200 x 600	0.071mm x 0.06	-	-
787#(2)	200 x 800	0.071mm x 0.05	-	-
787#(3)	200 x 1400	0.071mm x 0.04	12	0.8
795#	202 x 1760	0.05mm x 0.032	10	0.6
850#	216 x 1860	0.045mm x 0.030	9	-
1000#	254 x 2000	0.04mm x 0.028	8	0.5
1125#	285 x 2235	0.036mm x 0.025	7	-
1228#	312 x 2100	0.035mm x 0.025	-	-
1250#	318 x 2235	0.036mm x 0.025	-	-
1280#	325 x 2300	0.035mm x 0.025	5	0.45
1575#	400 x 3100	0.035mm x 0.019	3	-
Roll width: 1-1.6m
