BTO-22 Razor Barbed Wire Hot Dipped Galvanized 600mm 900mm Coil diameter in panel

Product Details:

Place of Origin:	Hebei,china
Brand Name:	XKh
Certification:	iso,ce
Model Number:	Razor barbed wire

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	Negotiable
Delivery Time:	7 days
Payment Terms:	T/T, L/C
Supply Ability:	50tons/day

Contact Now

Detailed Product Description

Item:	Hot Dipped Galvanized BTO-22 Flat Wrap Razor Wire In Panel Used On Wall Top	Material::	Hot Dipped /electric Galvanized Iron Wire Or Stainless Steel Wire As Core Wire ,hot Dipped Galvanized Sheet Or Stainless Steel Sheet As Blade
Blade Type::	Bto 10 , 15,18, 22 , 28,30 And CBT 60 65	Coil Diameter:	300mm,450mm,600mm,900mm Etc
Coil Clipped Space::	10-30cm	Shape::	Flat Wrap Panel Sheet
Core Wire Diameter::	1.8mm-2.75mm (2.5mm)	Blade Thickness::	0.3-0.5mm (0.45mm)
Application::	As Standalone Fence, Or Can Be Amalgamated With Existing Chain Link Mesh Or Other Fence , Tied On That	High Light::	BTO-22 Razor Barbed Wire, 600mm Razor Barbed Wire, 900mm Galvanized Razor Wire

Hot dipped galvanized BTO-22 flat wrap razor wire in panel used on wall top

Descriptions :

Flat warp razor barbed wire is a new type of razor barbed wire. Metal Tec press the single loop razor barbed wire into flat, or press two loops into flat then expand them across. We usually use it together with beenline razor barbed wire to build a defencing wall, or use it alone as a fence.

It is normally used in community, storehouse, mine, prison, key sites of National Defence, etc..

BTO22 in blade length 22mm , is the moest popular in razor barbed wire using .

BTO-22 Razor Barbed Wire Hot Dipped Galvanized 600mm 900mm Coil diameter in panel 0

Quick details :

Material :Hot dipped /electric galvanized iron wire or stainless steel wire as core wire ,hot dipped galvanized sheet or stainless steel sheet as blade
Blade type : BTO 10 ,15,18,22,25,28,30 & CBT 60 or 65
Coil diameter : 300mm,450mm,500mm,600mm,700mm,730mm,850mm,900mm,1050mm,1200mm (300-1200mm)
Coil clipped space : 10-35cm (as per request , 15-20cm will be in big density and high security )
Core wire thickness :1.8-2.75mm(2.5mm is the standard )
Blade thickness : 0.3-0.5mm (0.45mm is the standard )
structure shape : in roll (15m is the standard )or in sheet (2m is better considering container size )

Reference Number	BTO-12	BTO-15	BTO-22	BTO-25	BTO-30	CBT-60	CBT-65
Include Razor type

Model	Thickness	Wire Dia	Length	Width	spacing
BTO-10	0.5mm	2.5mm	12mm	13mm	26mm
BTO-12	0.5mm	2.5mm	12mm	15mm	26mm
BTO-18	0.5mm	2.5mm	18mm	15mm	33mm
BTO-22	0.5mm	2.5mm	22mm	15mm	34mm
BTO-28	0.5mm	2.5mm	28mm	15mm	34mm
BTO-30	0.5mm	2.5mm	30mm	18mm	34mm
CBT-60	0.6mm	2.5mm	60mm	32mm	96mm
CBT-65	0.6mm	2.5mm	65mm	21mm	100mm

Flat warp razor barbed wire

BTO-22 Razor Barbed Wire Hot Dipped Galvanized 600mm 900mm Coil diameter in panel 8

width	loops/roll	length/roll	Blade type
450mm	126	16M	BTO-10,12,18,22,28,30
600mm	95	16M	BTO-10,12,18,22,28,30
900mm	63	16M	BTO-10,12,18,22,28,30
1100mm	51	16M	BTO-10,12,18,22,28,30

Applications :

Installed against the existing smooth wire mesh fence;
Fitted to the welded mesh fence;
Fitted by overlapping the fence mesh;
Installed to the brick wall directly.

Notice : BTO-22 Razor Barbed Wire Hot Dipped Galvanized 600mm 900mm Coil diameter in panel 9

Flat wrap razor wire normally the coil diameter is 450mm ,500mm, 900mm
Roll length : standard is 15m or 16m , for the sheet is 2mtrs
Clipped space , we will suggest you when you have special request .
Packing : roll compacted - normally 5 rolls as one bundle .1 layer packing is thick waterproof paper , 2 layers -add woven bag . 3 layers need to add pallet .
Payment term : L/C,T/T or any 3rd platform's insurance order way .

BTO-22 Razor Barbed Wire Hot Dipped Galvanized 600mm 900mm Coil diameter in panel 10
