China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    • China ready stock 50 x50 mm euro fence mesh Pvc coating made in china
    • China ready stock 50 x50 mm euro fence mesh Pvc coating made in china
    • China ready stock 50 x50 mm euro fence mesh Pvc coating made in china
    • China ready stock 50 x50 mm euro fence mesh Pvc coating made in china
    • China ready stock 50 x50 mm euro fence mesh Pvc coating made in china
  • China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    Product Details:

    Place of Origin: Hebei province ,china
    Brand Name: HIghui
    Certification: ISO9001:2000,CE,SGS,COC
    Model Number: EURO FENCE

    Payment & Shipping Terms:

    Minimum Order Quantity: 1ROLLS
    Price: Price based on quantity
    Packaging Details: CUSTOMERIZED
    Delivery Time: 5-8 working days
    Payment Terms: L/C&TT& paypal
    Supply Ability: 1000 rolls /day
    Contact Now
    Detailed Product Description
    Material: Low Carbon Steel Wire Surface: Galvanized (hot Or Electric ) + Pvc Coating /vinly Coating
    Color: Green (light , Or Deep Green ) ,yellow , White , Dark ,,, Etc Shape: One Is Bending /v Type Like Wave , Or Without
    Hole: 3x3cm,5x5cm,6x6cm,5x10 Cm ,7.5x10cm Etc Height: 1m,1.5m,1.8m,2m,2.5m,3m ,etc
    Length: 18m, 30m ,etc MOQ: Stock Always

             China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



    1.INTRODUCTION :

    Material : Q195Low carbon steel wire

    Wire Diameter: 2.0mm-3.5mm(after coating )

    Wire surface treatment : Galvanized core wire + PVC(plastic powder coating )

    Hole Aperture :

                               with V stample /wave shape : 50*50,50*100,50*75,75*100mm,100*100mm(or customerized )

                               Without V shape /wave shape : 15x15mm,30mmx30mm, 60mmx60mm , 50x110mm ( A large stock for Green & Yellow color )

    Width of roll : 60cm , 90cm , 100cm , 150cm , 180cm , 200cm

    .Height : 10m,18m,25m, 30m(or customerized )

    Distance Between The Two Fence Posts: 3m

     Distance Between The Two Inclined Posts: 30m

     Plastic Color: Dark Green/Grass Green/White /Yellow /Red



    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china







    Wire Diameter : (After PVC coating )



    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    Traditional Holland Wire Mesh-With V shaped (wave ) - :



    Euro fence (Light)— Economic type

    Mesh Size: 100 x 75mm

    Wire Diameter: 1.7/2.1mm

    For private residence,parks and garden use.

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    Eurofence (Strong)— Durable type

    Mesh Size: 100 x 50mm

    Wire Diameter: 2.0/2.5mm

    For industrial and sport areas,garden use.

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



    Euro fence Standard

    Mesh Size: 100 x 50mm

    Wire Diameter: 1.7/2.1mm

    To be the traditional and elegant fence which particularly suitable for private residences and gardens.

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    Euro fence Plus

    Mesh Size: 100 x 50mm

    Wire Diameter: 1.7/2.1mm

    To be strengthening, for private residences and garden use.

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    Euro fence Promo

    Mesh Size: 100 x 100mm

    Wire Diameter: 1.6/2.0mm

    To be most economic fence for private

    redifence and garden.

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    Euro fence Forti

    Mesh Size: 50 x 50mm

    Wire Diameter: 2.0/2.5mm

    2.5/3.0mm

    Standing out on top seivage, without using the defensive barbs. To be most strong and secured

    fence for industry, sport areas

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    -Holland Wire Mesh Without V shaped (wave ) -: (also as welded wire mesh )

    (for low cost and also strengthen , adopt thicker wire and hard plastic costing (80% core wire thick +20% plastic coating  )

    we have large stock for Green color & Yellow color



     Small Hole : 1.5cmx1.5cm (1/2 inchx1/2 inch ) 3 cm x 3cm , 5x5 cm , 6x6cm .





    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



    2. Prepare installation :

    When we install it as fence , we will choose the post -peach type and round type post , but the most suitable type is swallow tail post :

    Post Color : Green ,Yellow , Red ... etc





                              OD : 48MM is standard ( other will be customerized )

     China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



     ( 0.55mm wall thick)                   (0.8mm wall thick )           ( 1.0mm or 1.2mm wall Thick)

     China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

                                        Galvanized tube + PVC coatig

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

              Swallow tail post : Two type -embedded post and post with base plate



      China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



                                  001 First step : prepare associate parts : clips , anti -rain cap & pliers :



    China ready stock 50 x50 mm euro fence mesh Pvc coating made in chinaChina ready stock 50 x50 mm euro fence mesh Pvc coating made in china



                                 002 Second step : Fixed two types of post in different of ground condition



    Embedded post -

    (dig hole , put post and fill full of soil , if want more strong , then we can for long-term use,   it will be better if pour with concrete or lime. normally it is 30cm deepth , but if above 1.8m - need to bear more pressure , we suggest 50cm  embedded deepth ,)

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



    Post with base plate -

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



    Inclined Post -( every 30meter )



    One or double



    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



                              003 Third step : FixHolland /welded Mesh

    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china

    3. Application :

        used widely in industry, agriculture, building, transportation, mine, field, lawn, cultivation etc professions'guard  and decoration



    China ready stock 50 x50 mm euro fence mesh Pvc coating made in china



       WELCOME YOUR VALUED INQUIRY :

       Mobile /whatsapp/wechat :008618730291422

       E-mail : alisawiremesh@hotmail.com

       Person : Alisa Zhou



       We Have larges stock for green and yellow color in 6x6cm in 1m,1.2m,1.5m,1.8m,2m

       And also Your customerized specification is our pleasure also .
