    Product Details:

    Place of Origin: Hebei ,China
    Brand Name: XK
    Certification: ISO 9000
    Model Number: Hot Dipped Galvanized Welded Gabion as a fence around private residence
    Contact Now
    Detailed Product Description
    Material: Steel Wire Surface Treatment: Hot Dip Galvanized,Heavy Zinc Coating ,zinc-alu Alloy Coated(Galfan)
    Mesh Size: 80X100-120X150MM Application: Gabion
    Hole Shape: Hexagonal Packing: Packed With Plastic Film Then On The Pallets Or Bulk

                      Hot Dipped Galvanized Welded Gabion as a fence around private residence



    OUR ADVANTAGE :we can do customerized welded gabion for beautify our life and landscape



    1.Introduction of Hot Dipped Galvanized Welded Gabion as a fence around private residence



    Hot Dipped Galvanized Welded Gabion as a  fence around private residence



    Welded gabion box is made of welded wire mesh panels assembled with spirals locking pins and stiffener. The philosophy of the Welded gabion is similar to woven gabions. Weld gabion units consist of panels of welded wire mesh, secured together to form a gabion unit, which is filled on site with gabion stone to form the appropriate structure.

    Whereas double twiste hexagonal woven mesh gabions are used in demanding engineering and geotechnical applications, welded gabions are popular in architectural applications, such as residential decroation and landscape construction. Welded mesh gabion units should not be used in watercourses due to the risk of differential settlement.

    Welded gabion shows ecology advantage and aesthetic appearance. Unlike other types of materials such a modular block walls the gabion stones do not discolor due to drainage. The longer a gabion or reno mattress structure is in place and becomes inundated with vegetation, the more aesthetic it becomes.

    Welded Gabion Box is made from Low Carbon Steel Wire.

    Surface Treatment available with Zinc Coated Welded Gabion, PVC Coated Welded Gabion, Galfan Coated Welded Gabion. PVC coated gabion is not very common in welded type.

    Wire Thickness: 3.0-6.0mm

    Mesh Opening Sizes: 50x50mm, 75x75mm, 100x100mm, 50x100mm, 50x200mm, 100X200mm etc.

    Gabion Box Dimension: 0.5x0.5x0.5m, 1x0.5x0.5m, 1x1x1m, 2x1x0.5m, 2x1x1m, 3x1x0.5m, 3x1x1m, 4x1x0.5m, 4x1x1m etc.



     Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    2.Manufacture of Hot Dipped Galvanized Welded Gabion as a fence around private residence

      A. PREPARE RAW MATERIAL -Steel wire

         AS EXAMPLE : HUAYANG BRAND .( adopt China big factory , assure zinc coating is good and diameter is in exact )



        Hot Dipped Galvanized Welded Gabion as a  fence around private residenceHot Dipped Galvanized Welded Gabion as a  fence around private residence

    B. Weavig Gabion Mesh Panel

        (we use best machine to weave , it assure the welded points is strong  and clean , and assure hole is more fixed )



       Below is our workshop:-Gabion mesh panel ready



      Hot Dipped Galvanized Welded Gabion as a  fence around private residence



    Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    C.  Prepare -Spirals & Stiffener/Hook ,etc  and start to install well :





                    SPIRALS                           Hooks /Stiffeners                        Mesh panel

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    D. Intall well of Hot Dipped Galvanized Welded Gabion as a fence around private residence



    Step 1. Ends, diaphragms, front and back panels are placed upright on the bottom section of wire mesh.
    Step 2. Secure panels by screwing spiral binders through the mesh openings in adjacent panels.
    Step 3. Stiffeners shall be placed across the corners, at 300mm from the corner. Providing a diagonal bracing, and crimped over the line and cross wires on the front and side faces. None are needed in interior cells.
    Step 4. Gabion box is filled with graded stone by hand or with a shovel.
    Step 5. After filling, close the lid and secure with spiral binders at the diaphragms, ends, front and back.
    Step 6. When stacking tiers of the welded gabion box, the lid of the lower tier may serve as the base of the upper tier. Secure with spiral binders and add pre-formed stiffeners to exterior cells before filling with graded stones.

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    3.Packing of Hot Dipped Galvanized Welded Gabion as a fence around private residence



      -- Pallet or carton

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence



    4.Application of Hot Dipped Galvanized Welded Gabion as a fence around private residence



    Control and guide of water or flood
    Flood bank or guiding bank
    Preventing of rock breaking
    Water and soil protection
    Bridge protection
    Strengthening structure of soil.
    Protection engineering of seaside area.



    Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence



     For the shape , we can do as customer real need

    Example : we make S shape for our customer as below :

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence

    Hot Dipped Galvanized Welded Gabion as a  fence around private residenceHot Dipped Galvanized Welded Gabion as a  fence around private residence



    And we also do other gabion mesh :

    Example : hexagonal hole  & Hesco barrier

    Hot Dipped Galvanized Welded Gabion as a  fence around private residence
