EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
    • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
    • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
    • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
    • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
    • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
    • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
    • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
  • EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    Product Details:

    Place of Origin: Hebei Province,china
    Brand Name: Xingkuan
    Certification: ISO9001:2000,CE,SGS,COC
    Model Number: Razor barbed wire

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 roll
    Price: Price based on quantity
    Packaging Details: waterproof paper inside , woven bag out side ,pallet or cartn also available
    Delivery Time: 7 days
    Payment Terms: L/C,TT
    Supply Ability: 4 cotainers /week
    Contact Now
    Detailed Product Description
    Material: Hot Dipped Galvanized Iron /steel Wire With Steel Sheet Core Wire Thickness: 2mm-2.5mm
    Blade Thickness: 0.35mm-0.5mm Type: BTO-10,BTO-22,BTO-28,BTO-30,CBT-60,CBT-60
    Coil Diameter: 300mm,350mm,400mm,450mm,500mm,550mm,600mm,700mm,900mm,1050mm Weight: 3 Kg - 15 Kg /coil
    Surface Treatment: Glavanized , PVC Coating ,Epoxy Machine: HIgh Speed Punching Machine

    Egypt Hama Holding bto22 razor wire with clips ( double)

    BTO 22 RAZOR WIRE Thickness 0.50mm +/- 0.05mm
    Wire Diam. 2.50mm +/- 0.05mm

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    BTO22 RAZOR WIRE  HOT GALBANIZED RAZOR WIRETO EGYPT SAID RAZOR WIRE



    Commodity and packing

    Specification

    Quantity



    Unit Price









    Inner packing is plastic film



    Outer packing is woven bag strip

    NO. BTO22

    Material HOT GALBANIZEDRAZOR WIREwith clips ( Double ) made byhot dipped galvanized steel plate

    Thickness 0.50mm +/- 0.05mm
     Wire Diam. 2.50mm +/- 0.05mm

     Barb Length 22mm

    m +/- 1mm
     Barb Width 15 +/- 1mm
     Barb Spacing 34mm +/- 1mm
    1 Metric Ton 1450Meter

    Outer diameter 1m(1000mm)

    number of loops 56





    1x 20GP

    18MT




    USD955/MT CIF Said, Egypt

    change by material price

    Total  Amount  CIF Said, Egypt

    USD



    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    BTO-22 - Material. HD Galvanized Zinc as below photo
    Thickness: 0.50 mm +/- 0.05 mm
    Wire diam: 2.50 mm +/- 0.05 mm
    Bars length: 22 mm +/- 1 mm
    Bars spacing: 34 mm +/- 1mm
    450 mm diameter and 35 rings
    Straight length: 46.5 mt per roll after pull open
    Standard covered length: 10 mt
    Inner packing: in plastic film
    Outer packing: in weaving brag strip.

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )



    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    Razor Barbed Tape Wire Specification

    Outside Diameter

    No. of Loops

    Standard Length per Coil

    Type

    Notes

    450mm

    33

    7-8M

    CBT-60.65

    Single coil

    500mm

    56

    12-13M

    CBT-60.65

    Single coil

    700mm

    56

    13-14M

    CBT-60.65

    Single coil

    960mm

    56

    14-15M

    CBT-60.65

    Single coil

    450mm

    56

    8-9M (3 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    500mm

    56

    9-10M (3 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    600mm

    56

    10-11M (3 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    600mm

    56

    8-10M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    700mm

    56

    10-12M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    800mm

    56

    11-13M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    900mm

    56

    12-14M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    960mm

    56

    13-15M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    980mm

    56

    14-16M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type



    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    Packing of razor barbed wire :

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    Application of   Cheap China Sharp blade BTO-22/CBT-65 Razor Wire



      razor type barbed wire is widely used in high-grade residence district, warehouses, prisons and in military fields and other sites requiring severe fencing and security.

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )



    alisa : mobile : +86-18730291422 ( whats app )  Mail :alisawiremesh@hotmail.com  Wechat : perfectme88

    EGYPT HAMA HOLDING BTO22 RAZOR WIRE WITH CLIPS ( DOUBLE )
