450mm,600mm,900mm,960mm,980mm coil diameter fencing concertina wire roll
Material: High quality low carbon steel wire / Hot dipped Galvanzied Iron Wire
Usage: Mainly Used for the importance safeguard, such as the frontier defense line Wire, sentry, prison, military base and airport, etc.
Specification: BTO-10,12,18,22,28,30,CBT-60,65.
1.Razor thickness:0.5mm
2.Wire diameter:2.5mm
3.Razor width: 15 mm
4.Razor length: 22 mm
5.Outside diameter of roll:600 mm
6.Number of loops:33--102
7.Standard spreading length per roll:8m --16m
8.Razor barbed type: cross type
Picture show:
1. Cross wire type - with 4 handles:
2. Cross wire type - without Handles ( with 3/5 clips ):
3. Helical /Single Coil wire type - without any clips
4. Flatwrap razor wire
5. Many Colors of PVC/Expocy razor concertina wire:
|
Barbed Tape Wire Specification:
|
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Type
|
Notes
|
|
450mm
|
33
|
8M
|
CBT-65
|
Single coil
|
|
500mm
|
41
|
10M
|
CBT-65
|
Single coil
|
|
700mm
|
41
|
10M
|
CBT-65
|
Single coil
|
|
960mm
|
53
|
13M
|
CBT-65
|
Single coil
|
|
500mm
|
102
|
16M
|
BTO-10.15.22
|
Cross type
|
|
600mm
|
86
|
14M
|
BTO-10.15.22
|
Cross type
|
|
700mm
|
72
|
12M
|
BTO-10.15.22
|
Cross type
|
|
800mm
|
64
|
10M
|
BTO-10.15.22
|
Cross type
|
|
960mm
|
52
|
9M
|
BTO-10.15.22
|
Cross type
|
| Notes: Standard products are shown in the tables above, special specifications Available on request. Standard materials are either galvanized or Stainless steel. |
| REference Number |
Thickness |
Wire Dia |
Barb Length |
Barb Width |
Barb spacing |
| BTO-10 |
0.50.05 |
2.50.1 |
101 |
131 |
251 |
| BTO-12 |
0.50.05 |
2.50.1 |
121 |
151 |
251 |
| BTO-18 |
0.50.05 |
2.50.1 |
181 |
151 |
351 |
| BTO-22 |
0.50.05 |
2.50.1 |
221 |
151 |
361 |
| BTO-28 |
0.50.05 |
2.5 |
28 |
15 |
461 |
| BTO-30 |
0.50.05 |
2.5 |
30 |
18 |
461 |
| CBT-65 |
0.60.05 |
2.50.1 |
652 |
211 |
1012 |
Packing of Razor wire :
1.Waterproof paper inside,woven bag outside
2. with good wood /metal pallet
3.Carton box
